• Model NO.：SY-0755
• Trademark：SAMYON
• Origin：Cn
• HS Code：903180
• Production Capacity：100sets Per Month

1.The frequency of rolling compaction44 time/min +1time/min 2.Crank radius 152mm+2mm3.The size of the rubber wheeldiameter is 76.5mm+1mm and width is 26.0mm+1.0mm4.The hardness of the rubber wheelHRC60~HRC705.Loaded weight of the rubber wheel total weight for the trolley horizontally placed is 56.7kg+0.5kg 6.Test modethickness 6.4mm and 12.7 mm are taken as the options .Inner dimension is 50mm*380mm7.Sand frame inner dimension is 355.0mm*38.0mm*0.5mm8.Steel coverdimension is 353mm*36mm*3mm9.Physical dimension 1400mm*260mm*450mm10.Power supply AC380V,50Hz,550W(three-phase four-wire system,with zero line)
1.The frequency of rolling compaction :44 time/min +1time/min
2.Crank radius :152mm+2mm
3.The size of the rubber wheel :diameter is 76.5mm+1mm and width is 26.0mm+1.0mm
4.The hardness of the rubber wheel :HRC60~HRC70
5.Loaded weight of the rubber wheel :total weight for the trolley horizontally placed is 56.7kg+0.5kg
6.Test mode :thickness 6.4mm and 12.7 mm are taken as the options .Inner dimension is 50mm*380mm
7.Sand frame :inner dimension is 355.0mm*38.0mm*0.5mm
8.Steel cover :dimension is 353mm*36mm*3mm
9.Physical dimension :1400mm*260mm*450mm
10.Power supply :AC380V,50Hz,550W(three-phase four-wire system,with zero line)

III.Choice of the accessories
1.Platform balance :weigh 100kg ,reciprocal sensibility ≤0.5kg
2.Balance :weigh 2000g,reciprocal sensibility ≤1g
3.Bake oven :with forced draft ,the temperature can be controlled in (60+3)ºC
