• Model NO.：SY-2806G
• Transport Package：Carton Case
• Specification：SGS
• Trademark：SAMYON
• Origin：Cn
• HS Code：9031809090
• Production Capacity：100sets Per Month

1. Power supplyAC 220V (-5%~+10%), 50 Hz;2. Measurement range32 ºC~160 ºC.
(1) Heating medium: distilled water(softening point under 80 ºC)
(2) Heating medium: glycerin (softening point over 80 ºC)3. Temperature resolution0.01 ºC4. Cubage of beaker1000 ml5. Stirrerthe stirring speed can be adjusted continuously.6. Heating rateit will be adjusted to 5.0±0.5 ºC/ min automatically after three minutes7. Heating power600 W8. Test resultLCD screen shows results and printer to print.9. Computer communication interfaceRS232C communication interface10. Ambient temperatureThe temperature should be lower than 35 ºC and keep stable. There should not have any air draft.11. Relative humidity≤85%12. Total power consumption≤700 W13. Test sample2 samples
1. Power supply: AC 220V (-5%~+10%), 50 Hz;
2. Measurement range: 32 ºC~160 ºC.
  (1) Heating medium: distilled water(softening point under 80 ºC)
  (2) Heating medium: glycerin (softening point over 80 ºC)
3. Temperature resolution: 0.01 ºC
4. Cubage of beaker: 1000 ml
5. Stirrer: the stirring speed can be adjusted continuously.
6. Heating rate: it will be adjusted to 5.0±0.5 ºC/ min automatically after three minutes
7. Heating power: 600 W
8. Test result: LCD screen shows results and printer to print.
9. Computer communication interface: RS232C communication interface
10. Ambient temperature: The temperature should be lower than 35 ºC and keep stable. There should not have any air draft.
11. Relative humidity: ≤85%
12. Total power consumption: ≤700 W
13. Test sample: 2 samples
