• Model NO.：SY-265H
• Specification：SGS
• Trademark：SAMYON
• Origin：Cn
• HS Code：903180
• Production Capacity：100sets Per Month

1. Power supplyAC(220±10%)V, 50Hz2. Bath heating power1700W3. Temperature rangeRoom temperature~100.0ºC4. Temperature control accuracy±0.01ºC5. Bath volume20L6. Timing range0.0s~9999.9s7. Timing accuracy±0.05% within 60min8. Amount of capillary viscometer tubes4 capillary viscometers9. Stirring motorPower 6W, rotating rate 1200RPM10.Working conditionambient temperature-10ºC~35ºC, RH: ≤85%11.Temperature sensorRTD, Pt10012.Maximum power consumption1800W13.Capillary viscometers tubes(Pinkevitch viscometer)7 pieces in total.The inner diameter for each: 0.6mm, 0.8mm, 1.0mm, 1.2mm, 1.5mm, 2.0mm, 2.5mm14.Dimension530mm×400mm×670mm
1. Power supply:AC(220±10%)V, 50Hz
2. Bath heating power:1700W
3. Temperature range:Room temperature~100.0ºC
4. Temperature control accuracy:±0.01ºC
5. Bath volume:20L
6. Timing range: 0.0s~9999.9s
7. Timing accuracy: ±0.05% within 60min
8. Amount of capillary viscometer tubes: 4 capillary viscometers
9. Stirring motor: Power 6W, rotating rate 1200RPM
10.Working condition: ambient temperature-10ºC~35ºC, RH: ≤85%
11.Temperature sensor: RTD, Pt100
12.Maximum power consumption: 1800W
13.Capillary viscometers tubes(Pinkevitch viscometer): 7 pieces in total.The inner diameter for each: 0.6mm, 0.8mm, 1.0mm, 1.2mm, 1.5mm, 2.0mm, 2.5mm
14.Dimension:  530mm×400mm×670mm
