• Model NO.：SY-265C
• Trademark：SAMYON
• Origin：Cn
• HS Code：903180
• Production Capacity：100sets Per Month

Power supplyAC(220±10%)V,50Hz±5%Heating power1600WStirring motorPower is 6W,rotating speed 1200RPMTemperature control rangeRoom temperature~100ºCTemperature control accuracy±0.1ºCConstant temperature bath20L,double shell structureWorking environmentAmbient temperature: room temperature~35ºC;
Relative humidity: ≤85%Temperature sensorRTD, Pt100Maximum power consumption1800WCapillary viscometer tubes(Pinkevitch viscometer)7 pieces in total, inner diameter for each: 0.6mm, 0.8mm, 1.0mm, 1.2mm, 1.5mm, 2.0mm, 2.5mmDimension530mm×400mm×670mm;
Net weight: about 33Kg
1. Power supply:     AC(220±10%)V,50Hz±5%
2. Heating power:    1600W
3. Stirring motor:     Power is 6W,rotating speed 1200RPM
4. Temperature control range:      Room temperature~100ºC
5. Temperature control accuracy:    ±0.1ºC
6. Constant temperature bath:     20L,double shell structure
7. Working environment:   Ambient temperature: room temperature~35ºC
                                                Relative humidity: ≤85%
8. Temperature sensor:    RTD, Pt100
9. Maximum power consumption:   1800W
10. Capillary viscometer tubes(Pinkevitch viscometer):7 pieces in total, inner diameter for each: 0.6mm, 0.8mm, 1.0mm, 1.2mm, 1.5mm, 2.0mm, 2.5mm
11. Dimension:  530mm×400mm×670mm;Net weight: about 33Kg
