• Model NO.：SY-6536B
• Trademark：SAMYON
• Origin：Cn
• HS Code：903180
• Production Capacity：100sets Per Month

I. Main technical features
1.The instrument adopts low temperature and double units working mode. The minimum temperature can set to 0ºC.It can do test for one sample or two samples at same time.It highly improves the work efficiency.
2.It adopts digital temperature controller, stainless-steel heater, new type refrigeration compressor and electric stirrer to constitute constant temperature bath. The temperature in the bath is uniform,can fully meet the requirements of test.
3.It adopts special designed structure, cooling speed is fast.The bath temperature can cool down from room temperature to 0ºC within 50 minutes.
4.It adopts special heating furnace to ensure the safety of test. Heating power can be stepless adjusted to meet the requirements of test.

II. Main technical specifications1.Power supplyAC(220±10%)V, 50Hz2.Heating power1000W×23.Receiving cylinder100ml, division value is 1ml4.Distillation flask125ml,meet the requirements of GB/T 6536 and ASTM D865.Thermometer(-2~300)ºC and (-2~400)ºC. Division value 1ºC6.Flask support boardSiC, bore diameter is: φ32mm, φ38mm, φ50mm7.Temperature controller(1)Control range: 0ºC~60ºC
(2)Accuracy: ±0.5ºC
(3)Temperature display: LED
Note: The temperature control is to control the temperature of condensate in the condenser pipe.8.Ambient temperature ≤30ºC9.Relative humidity ≤85%10.Cooling system New type refrigeration compressor11.Maximum power consumption 4000W12.Dimension730mm×530mm×580mm
1.Power supply:  AC(220±10%)V, 50Hz
2.Heating power: 1000W×2.
3.Receiving cylinder: 100ml, division value is 1ml.
4.Distillation flask: 125ml,meet the requirements of GB/T 6536 and ASTM D86
5.Thermometer:(-2~300)ºC and (-2~400)ºC. Division value 1ºC.
6.Flask support board: SiC, bore diameter is: φ32mm, φ38mm, φ50mm.
7.Temperature controller:(1)Control range: 0ºC~60ºC
                                    (2)Accuracy: ±0.5ºC
                                 (3)Temperature display: LED
Note: The temperature control is to control the temperature of condensate in the condenser pipe.
8.Ambient temperature: ≤30ºC
9.Relative humidity: ≤85%
10.Cooling system: New type refrigeration compressor
11.Maximum power consumption:  4000W
12.Dimension:730mm×530mm×580mm
