Cecs 21: 2000 Concrete Pile Defect Tester

Beijing Samyon Instruments Co., Ltd.

Receive Channel：One
Size：260*185*60mm
Transmission Mode：Continuous and External
Amplifier Bandwidth：10kHz to 300kHz
Sound Time Accuracy：0.05us
Transport Package：Carton Case

Base Info

Model NO.：SYC61
Specification：SGS
Trademark：SAMYON
Origin：Cn
HS Code：903180
Production Capacity：100sets Per Month

Description

ItemSpecificationMain control unitHigh-performance embedded computerInput methodkeyboardInterfaceUSBReceive channeloneTransmission modeContinuous and externalReceive sensitivity≤30uvAmplifier bandwidth10kHz to 300kHzSound time accuracy0.05usDisplay640*480 high brightness TFT panelStorage1G(Interior)
2G(U-Disk)Max sample data length64kTrigger voltage65,125,250,500,1000(selectable)Amplifier gain82dBSample periods0.05us to 6.4us,8grade adjustableAmplifier resolution0.39%PowerInterior lithium battery works more than 6hoursExternal lithium battery works more than 6hours (Optional)DC 12V interfaceAC 100V-240V,50/60HZSize260*185*60mmWeight1.75kg(including the batteryTemperature-10ºC~ +40ºC
Cecs 21: 2000 Concrete Pile Defect Tester

Cecs 21: 2000 Concrete Pile Defect Tester

Cecs 21: 2000 Concrete Pile Defect Tester

Cecs 21: 2000 Concrete Pile Defect Tester

Cecs 21: 2000 Concrete Pile Defect Tester
