• Model NO.：DP1
• Sensitivity：0.1c
• Signal Outputs：4-20mA or 0-5V DC Isolated
• Sample Gas Flow Speed：1-3L,Min
• Transport Package：Carton
• Specification：CE
• Trademark：BROTIE
• Origin：China
• HS Code：9027100090
• Production Capacity：10000sets,Year

Range:Basic type: +20ºC~-60ºCStandard type:+20ºC~-80ºCExpanding type:+20ºC~-100ºCAccuracy:±1% F.SResponse time:T90≤5minSensitivity:0.1ºCStability:Zero drift ≤2% of FS/7d, Span drift ≤2% of FS/7dRepeatability:Cv≤1ºCSample gas pressure:0.05MPa≤Inlet pressure≤0.5MPaSample gas flow speed:1-3l/mimContact capacity:125VAC 0.3A, 110VDC 0.3A, 30VDC 1ASignal outputs:4-20mA or 0-5V DC isolatedPower supply:220±10%VAC, 50/60Hz, power loss≤10VAWorking temperature:0ºC-+45ºCEnvironment humidity:≤90%RHInstallation dimension:133mm*133mm*250mmWeight:3.5kg
