• Model NO.：HT-LA610
• Type：Zirconia
• Test Principle：Zirconia
• Transport Package：Cartoon Box
• Specification：142*208*86(mm)
• Trademark：HT
• Origin：China
• HS Code：9027100090
• Production Capacity：200 Pieces, Month

Basic Info.

Model NO. HT-LA610 Type Zirconia Test Principle Zirconia Transport Package Cartoon Box Specification 142*208*86(mm) Trademark HT Origin China HS Code 9027100090 Production Capacity 200 Pieces/ Month

Product Description

Technical Specifications:
   Measurement Principle: Zirconia
   Display Mode: 128×64 dot matrix OLED
   Measurement Range:0~21.00%O₂
   Measurement Accuracy: ≤±1.0%FS
   Resolution: 0.01%
   Repeatability: ≤±1.0%FS
   Response Time: T90≤30S
   Output Port: 4-20mA (Non-isolated output, load resistance<1KΩ)
                       0-5V.DC (Non-isolated output, load resistance>10KΩ)
                       1 way of programmable alarm output (Dry contact type, maximum load 220V/2A)
   Communication Mode: RS2323 (default) or RS485
   Sampling Mode: In-site sampling
   Measurement Media: Combustion flue gas (except for strong corrosive and reducing gas)
   Operation Temperature: Instrument: -10ºC~+50ºC, probe: 0~700ºC
   Power Supply: AC220V±10% 50/60Hz, power dissipation <20VA
   Size: Instrument: 185mm×142mm×86mm (H×W×D)   Hole-Cutting Size: Φ40mm (minimum size)   Probe Length: normal length: 1m, other length is customizable (≤1.8m)   Connecting Method: Cable connecting (standard length 5 meters)   Sensor Service Life: >5 years (under normal conditions of use)   Installation Method: Instrument: Wall mounting                                   Probe: Plug-in (standard DN65 flanged mounting)

Features:   a.    Menu can be switched between Chinese and English;   b.    OLED active illumination display makes the operation easy and convenient;   c.    The new type zirconia sensor has a high measurement accuracy, rapid response speed and small drift value, etc.;   d.    PID automatic temperature control circuit could raise the temperature rapidly and accurately, eliminating the impact of out erenvironment changes on the temperature control;   e.    The original imported ceramic heater is used as the heat element to improve analyzer's serve life.   f.    It can be used within 700ºC for long-term use;  g.    The instrument allows multi-point fractional liner calibration, meeting the need for an accurate measurement of oxygen content among the full range;   h.    Error detection function could enhance the efficiency of debugging and its self-protection ability;  i.    The protection level of probe and instrument is IP54 (except for the front area of the probe), enabling them to be used in severe outdoor environment;   j.    Factory default settings can be restored, preventing analyzer parameters setting chaos resulted by mis-operation;   k.    5000 pieces of historical data can be stored automatically, enabling user to read historical data freely;
  m.    Users can set 4-20mA or 0-5V output corresponding oxygen concentration upper and lower limits freely, so that users can get more accurate analog output;  l.    RS232 (default) or RS485 digital communication port can be selected according to clients' requirement, to realize unidirectional or bidirectional communication with computer or other digital communication facilities.
 Application:
   It is widely used in air separation nitrogen production, smelting industry, medical and health care, petrochemical, electronic power and other industries, and oxygen concentration analysis in flue gas of various industrial boilers and furnaces flue gas, to improve combustion efficiency, save energy and reduce environmental pollution.

Order Notice (Please indicate following messages when placing orders)
   Probe length and its operation temperature
   Sample gas temperature
   Connecting cable length
   Background gas composition
