Brotie Trace Ppm Oxygen Analyzer Instrument
Brotie Technology Company Limited- Brand:TES
- Customized:Non-Customized
- Portable:Portable
- Gas:O2
- Type:Electrochemical Gas Analyzer
- Measure Range:0-10ppm, 0-100ppm, 0-1000ppm, 0-1% O2
Base Info
- Model NO.:PPM Level
- Accuracy:≤±2% in Fs Range
- Response Time:90% of Final Fs Reading ≤10 Seconds
- Display Resolution:0.01ppm
- Transport Package:Carton
- Specification:133mm× 133mm× 250mm
- Trademark:BROTIE
- Origin:China
- HS Code:9018193000
- Production Capacity:10000sets,Year
Description
Basic Info.
Model NO. PPM Level Accuracy ≤±2% in Fs Range Response Time 90% of Final Fs Reading ≤10 Seconds Display Resolution 0.01ppm Transport Package Carton Specification 133mm× 133mm× 250mm Trademark BROTIE Origin China HS Code 9018193000 Production Capacity 10000sets/YearProduct Description
Trace Oxygen AnalyzerFeatures
* Imported fuel cell oxygen sensor, long life, high precision and fast response
* Measuring oxygen concentration in H2 or deoxidize gas
* Inner special gas-route protects the sensor when it exposures in the air for a long timeby out of power or cutting off the gas-route automatically.
* Setting Upper and lower alarm values freely during the measure ranges.
* 4-20mA signal output
* One standard RS232C or RS485 interface
Technical Specifications
Measure Range | 0-100ppm, 0-1000ppm, 0-1%, 0-25% O2 |
Accuracy | ≤ ± 2% in FS range |
Response Time | 90% of final FS reading ≤ 5 seconds |
Display Resolution | 0.1ppm |
Stability | Zero drift ≤ ± 2% of FS/7d |
Span drift | ≤ ± 2% of FS/7d |
Repeatability | ≤ ± 1% |
Ambient Temp | 0~+60C |
Sampling Gas Flow | 200~400ml/MIM |
Sampling Gas Pressure | 0.035MPa≤ Inlet pressure≤ 0.21Mpa |
Power Supply | 220± 10% VAC, 50/60Hz, power loss≤ 20VA |
Measure Medium | N2, inert gases |
Contact Capacity | AC125V 0.3A, AC110V 0.5A, DC24V 3A |
Sensor Life | 24 months at 25C and 1 ATM |
Warranty | 12 months analyzer; 12 months sensor |
Weight | 3kg |
Installation Dimension | 133mm× 133mm× 250mm (W× H× D) |
