• Model NO.：P860
• Sensitive：0.01% O2
• Signal Outputs：4-20mA
• Sensor Life：3 Years (in Normal Condition)
• Warranty：12 Months Analyzer; 12 Months Sensor
• Response Time：90% of Fs Reading in 20 Seconds
• Sensor Principle：Ion Current Oxygen Sensor
• Appearance Dimension：160mm×80mm×176mm (W×h×d)
• Opening Size：151mm×75mm
• Transport Package：Carton
• Specification：ISO9001
• Trademark：BROTIE
• Origin：China
• HS Code：8414809090
• Production Capacity：10000sets,Year

Basic Info.

Model NO. P860 Sensitive 0.01% O2 Signal Outputs 4-20mA Sensor Life 3 Years (in Normal Condition) Warranty 12 Months Analyzer; 12 Months Sensor Response Time 90% of Fs Reading in 20 Seconds Sensor Principle Ion Current Oxygen Sensor Appearance Dimension 160mm×80mm×176mm (W×h×d) Opening Size 151mm×75mm Transport Package Carton Specification ISO9001 Trademark BROTIE Origin China HS Code 8414809090 Production Capacity 10000sets/Year

Product Description

Percentage Oxygen Analyzer

Features
* New pattern long-life conversion ion current tester with fast response and high sensitivity
* N2 or O2 concentration display
* Checking the sensor working state automatically and unique double-line working change mode extending the sensor's life
* Setting alarm value freely
* High precision, automatic temperature compensation, eliminating the impact of environmental temperature

Technical Specifications

Monitor:	Five-digital dynamic LED monitor, visible display window: 90mm×25mm
Measure Range	10~2000ppm, 0~2%, 0~21% O2
Sensor Principle	Ion current oxygen sensor
Measure Mode:	Air inflowing or convection diffusing
Sample Gas Flow:	150~300ml/min
Accuracy:	±5% in 10~2000ppm O2   ±2% in 0~2%O2 ran  ±1% in 0~21%O2 range
Response Time:	90% of FS reading ≤20 seconds
Ambient Temp	-10ºC~+50ºC
Ambient Humidity:	<80%RH
Stability:	<±1%.FS (168h)
Signal Output:	4~20mA
Power Supply:	220±10% VAC, 50/60Hz, the power loss ≤6VA
Sensor Life:	20000 hours at 25ºC and 1 atm
Warranty:	12 months analyzer; 12 months sensor
Weight:	1kg
Appearance Dimension:	160mm×80mm×176mm (W×H×D)
Opening Size:	151mm×75mm
