• Model NO.：HZCQ-516
• Ultimate Vacuum Degree：<133PA
• Device Load：8kgf,Cm²
• Voltage：380V 50Hz,60Hz
• Transport Package：Wooden Box with Wrapping Film
• Trademark：United
• Origin：Wuhan, China
• HS Code：9030339000

Basic Info.

Model NO. HZCQ-516 Ultimate Vacuum Degree <133PA Device Load 8kgf/Cm² Voltage 380V 50Hz/60Hz Transport Package Wooden Box with Wrapping Film Trademark United Origin Wuhan, China HS Code 9030339000

Product Description

Product Description:
HZCQ-516 Series vacuum pumping and inflation device is mainly used for vacuum pumping and vacuum degree determining of magnetic pole SF6 circuit breaker, transformer and other SF6 electric appliances when installation, operation and maintenance. The entire SF6 gas inflation and vacuum pumping device comprises a vacuum pump, a pointer type vacuum gauge, a regulating valve, a gas transmission pipe and a valve and SF6 circuit breaker necessary control components for maintaining.

Product Features:
1.Quick pumping.
2.Regulate pressure to inflate.
3.Solid structure.
4.High precision thermocouple vacuum gauge.

Product Parameters:

Vacuum Pumping Speed	12L/S 40m³/h	Ultimate Vacuum Degree	<133Pa
Leakage Rate	<1%	Device Load	8kgf/cm²
Weight	75kg	Voltage	380V 50Hz/60Hz

Company Profile
Wuhan Hezhong Electric Equipment Manufacture Co., Ltd is a high-tech enterprise professionally engaged in R & D, manufacture and marketing of power testing products, instruments, power industry automation systems for 20 years.We export completed set to Korea, Singapore, Vietnam, India, Ecuador, Paraguay, Pakistan, Philippines, Russia, Italy, Austria, Portugal, Chile such as PD test system, impulse voltage generator, temperature rising test system, transformer comprehensive test system, cable fault detect system and varies of instruments for transformer, circuit breaker, switchgear, lightning arrestor, insulator, cable, battery,SF6 gas and so on.
