• Model NO.：Creep
• Specification：SGS
• Trademark：SAMYON
• Origin：Cn
• HS Code：903180
• Production Capacity：100sets Per Month

Capacity500KNMeasuring range0~500KNPressure relative error±1%Spring sizeoutside:50×250×355mm;
inside:28×140×355mmSpring compression stroke<20mmDistance between platens1500mmSize of mould150×150×400mm,  φ150×500mm
Capacity:500KN
Measuring range:0~500KN
Pressure relative error:±1%
Spring size:outside:50×250×355mm
                     inside:28×140×355mm
Spring compression stroke:<20mm
Distance between platens:1500mm
Size of mould:150×150×400mm,  φ150×500mm

Purpose:
This equipment is used for measuring the compression of concrete creep test and tensile creep test, the main observation under constant compression or tensile load deformation of growth over time that the creep deformation of concrete.

Standard: GB/T50082-2009,SL352-2006.

Technical parameters:
Capacity:500KN
Measuring range:0~500KN
Pressure relative error:±1%
Spring size:outside:50×250×355mm
           inside:28×140×355mm
Spring compression stroke:<20mm
Distance between platens:1500mm
Size of mould:150×150×400mm,  φ150×500mm
