• Model NO.：SC80
• HS Code：9031809090
• Production Capacity：50 Piece,Pieces , Week

Basic Info.

Model NO. SC80 HS Code 9031809090 Production Capacity 50 Piece/Pieces / Week

Product Description

SC80 precise color reader(color meter, colorimeter) is mainly applied to plastic, painting, design, plating, costume, printing and dyeing industries. SC80 coloimeter can do the color analysis and color controlling. Compared with other color meter, it has many advantages:

KEY FEATURES:
The 2.4" colorful screen and portable design make you feel comfortable.
3 kinds of light sources for your selection, SCI and SCE mode switch and metamerism analysis satisfy your test needs in different working status.
Tolerance setting, auto-judge color difference values and color deviation make you judge the color easily even you don't have any professional knowledge in color.

Using professional color analysis software you can do the color data analysis and color difference diagrammatic outputting.
Via optional mini printer the color data can be printed out on site.
Similar model: TCR200

Model	SC80 ( color meter, colorimeter)
Accuracy	0.08 (average value of 30 times @ the standard white tabula)
Lighting/Inspecting system	8/d (8o falloff/diffuse reflection) SCI (include flat mirror light) / SCE (eliminate flat mirror light)
Light source	White light source
Inspection angle	10 degree angle of view in CIE
Inspection conditions	D65, D50, F11
Rectification	White board rectification Black board rectification
Storage	12 groups of standard samples, 30 groups of values for each sample
Display	L*a*b*, L*c*h* Chroma values and Δ E*ab Δ (L*a*b*), Δ (L*C*H*) color difference values
Language	English / Chinese
Aperture (mm)	Ø 8
Power supply	4 pcs of alkaline batteries or nickel batteries special adaptor (DC, 5V)
Net weight (g)	550g
Dimension (mm)	77x86x210
