3-Digit LCD Display Surface Roughness Tester
Sino Age Development Technology- Usage：Checking Surface Roughness
- Sensor Type：Piezoelectric
- Maximum Stylus Force：15.0mn,1500mgf
- Transport Package：Delivery Package: Carton
- Specification：CE, SGS
- Trademark：SADT
Base Info
- Model NO.：RoughScan
- Origin：China
- HS Code：90318090
- Production Capacity：200 Pieces,Month
Description
Basic Info.
Model NO. RoughScan Origin China HS Code 90318090 Production Capacity 200 Pieces/MonthProduct Description
SADT Surface Roughness Tester RoughScan details:SADT RoughScan tester is a portable, batterypowered instrument for checking surface roughness with the measured values displayed on a digital readout. The instrument can be used in the laboratory, an inspection area, in the shop, or wherever on-site surface roughness testing is required.
Specifications:
Measuring Range: Ra: 0.03μ M~6.3μ M/1μ "~250μ "
Rz: 0.2μ M~50.0μ M/8μ "~999μ "
Ry/Rmax: 0.2μ M~25μ M/8μ "~999μ "
Resolution: 0.01μ M/1μ "
Cut- off: 0.8mm/0.30", ANSI 2RC Filter
Display: 3-digit LCD
Readout Error: ± 10%
Stability: ≤ 6%
Sensor Type: Piezoelectric
Maximum stylus force: 15.0mN/1500mgf
Working Environment: 10oC~45oC
Storage Temperature: 0oC~60oC
Optional Probes:
1. General purpose probe SFP-2001/ SFP-2002
Application: For most sur f a ce roughness applications. SFP-2001 has a 90° Conical diamond st ylus, . 0004"/10μ M radius per ISO standards.
SFP-2002 has a 90° Conical diamond st ylus, . 0002"/5μ M radius per DIN standards.
2. Transverse chisel probe SFP-2003
Application: Fo r gaging sharp edges or small O. D. 's where probe is aligned with (in 180° Or closed position ) to axis of traverse. 9 0 ° Diamond chisel stylus, . 0004"/10μ M radius.
3. Parallel chisel probe SFP-2004
Application: Fo r gaging sharp edges o r small O. D. 's where probe is perpendicular ( in 90 ° Or 270 ° Position ) to axis of traverse. 9 0 ° Diamond chisel stylus, . 0004"/10μ M radius.
4. Small bore probe SFP-2005/SFP-2006
Application: For measuring small bore s (min. Inside diamete r o f 5.0mm, up to a depth of 15.0mm). 90° Conical diamond st ylus, . 0004"/10μ M radius for SFP-2005; 90° Conical diamond st ylus, . 0002"/5μ M radius for SFP-2006.
5. Groove bottom probe
Application: For measuring the bottoms of "O" ring grooves, recesses and holes to depth of 6.0mm. Also used for shor t lands and shoulders. 90° Conical diamond st ylus, . 0004"/10μ M radius.
| Traverse length | Evaluation length | Numbers of cutoff |
| 0.5mm | 0.25mm | 1 |
| 1 . 2mm | 0.8mm | 1 |
| 5.5mm | 5.0mm | 1 |
| 1.25mm | 0.75mm | 3 |
| 3 . 0mm | 2.4mm | 3 |
| 5.5mm | 5.0mm | 3 |
| 1.75mm | 1.25mm | 5 |
| 4 . 5mm | 4.0mm | 5 |
| 5.5mm | 5.0mm | 5 |
