Surface Roughness Tester with 15 Parameters
Sino Age Development Technology- Usage：Checking Surface Roughness
- Sensor Type：Piezoelectric
- Maximum Stylus Force：15.0mn,1500mgf
- Transport Package：Delivery Package: Carton
- Specification：CE, SGS
- Trademark：SADT
Base Info
- Model NO.：SR200
- Origin：China
- HS Code：90318090
- Production Capacity：200 Pieces,Month
Description
SADT SR200Measuring rangeZ Axis (Vertical)160μmX Axis (Horizontal)17.5mmResolutionZ Axis (Vertical)0.01μm/±20μm
0.02μm/±40μm
0.04μm/±80μmMeasurement itemParametersRa, Rq, Rz, Rt, Rp, Rv, RS, RSm, Rz(JIS), Ry(JIS) ,
RSk, R3z, Rmax, Rpc, Rmr;StandardsISO, ANSI, DIN, JISGraphicRoughness profile, Material ratio curve, Direct profileFilterRC, PC-RC, Gauss, D-PSampling length (lr)0.25,0.8,2.5mmAssessment length (ln)Ln= lr×n n=1~5ProbeprincipleDifferential inductanceStylusNatural Diamond, 90° cone angle, 5μm tip radiusForce<4mNSkidRuby, Longitudinal radius 40mmTraversing speedlr=0.25, Vt=0.135mm/s
lr=0.8, Vt=0. 5mm/s
lr=2. 5, Vt=1mm/s
Return Vt=1mm/sAccuracyLess than or equal to ±10%RepeatabilityLess than or equal to 6%Power supplyBuilt-in Lithium ion battery, AC adapter 8.4V, 800mADimension119×47×65mm (L×W×H)Weightapproximately 380g
0.02μm/±40μm
0.04μm/±80μmMeasurement itemParametersRa, Rq, Rz, Rt, Rp, Rv, RS, RSm, Rz(JIS), Ry(JIS) ,
RSk, R3z, Rmax, Rpc, Rmr;StandardsISO, ANSI, DIN, JISGraphicRoughness profile, Material ratio curve, Direct profileFilterRC, PC-RC, Gauss, D-PSampling length (lr)0.25,0.8,2.5mmAssessment length (ln)Ln= lr×n n=1~5ProbeprincipleDifferential inductanceStylusNatural Diamond, 90° cone angle, 5μm tip radiusForce<4mNSkidRuby, Longitudinal radius 40mmTraversing speedlr=0.25, Vt=0.135mm/s
lr=0.8, Vt=0. 5mm/s
lr=2. 5, Vt=1mm/s
Return Vt=1mm/sAccuracyLess than or equal to ±10%RepeatabilityLess than or equal to 6%Power supplyBuilt-in Lithium ion battery, AC adapter 8.4V, 800mADimension119×47×65mm (L×W×H)Weightapproximately 380g
