• Model NO.：YX-2002
• HS Code：9031809090
• Production Capacity：200 Sets,Month

Basic Info.

Model NO. YX-2002 HS Code 9031809090 Production Capacity 200 Sets/Month

Product Description

Laser Particle Size Analyzer
General Description
1. YX-2002 laser particle size analyzer, for CWM particle, coal powder, coarse particle, coarse gunpowder, gunpowder catalyst and non-metallic mineral powder test, is developed by National Project Technology Center of CWM.

2. The particle size analyzer utilizes the property that the CWM particles can cause laser diffraction and laser dispersion. Fast speed, easy operation and good repeatability, it is ideal particle size test instrument for CWM producer and user.

3. It includes optical testing and signal transforming device (main engine) comprising laser generator, spatial filter, laser beam collimation and laser beam expansion system, Fourier lens, prism, multi-element photoelectric receiver and electric circuit system, etc; Sample preparation device comprising disperser, stirrer, circulation pump, sample pool, sample feeding pipeline, etc; Computer device comprising computer, printer, test software, etc.

4. It gets particle diameter signal through laser dispersion created by optical testing device and sample preparation system, then transmit these signals to computer for CWM result. Besides, it can also test the particles of fairly coarse powder...


For more detail info, please feel free to visit our website or inquire us at any of your convenience...

Technicial Parameters
Size Range	0.68 μ m~951  μ m
Obscuration of suspension	40%-80%
Repeatability error	Less than 1%(on D50 of standard sample)
Test Time	Normally 1-3 mins
Gross weight(including all accessories and spare parts	60KG
External dimension	1000× 30× 30mm
Power	1000W
Voltage	AC220V, 5 A
