Gas Chromatography Fid Vocs Online Monitoring System
Nanjing KELISAIKE Safety Equipment Co., Ltd.- Customized：Customized
- Portable：Non Portable
Base Info
- Model NO.：WT800
- Certification：CE
- Gas：Vocs
- Type：Gas Chromatograph
- Measuring Principle：Principles of Gas Chromatography
- Measuring Components：Methane,Non-Methane Total Hydrocarbons, Benzene Se
- Measuring Range：0-1000ppm(Configurable)
- Methane：0-1000ppm
- Nmhc：0-10000ppm
- Benzene Series：0-1000ppm
- The Detection Limit：Methane 0.1ppm
- Repeatability：Rsd Less 3%
- Measurement Deviation：2%Fs
- Analysis Cycle：1.5min
- Response Time：90s(25m Heating Pipeline)
- Output：RS485, WLAN
- Transport Package：Wooden Box
- Specification：200*800*600mm
- Trademark：KELISAIKE
- Origin：China
- HS Code：9027100090
- Production Capacity：500
Description
(20%-90%)R
| Detector | Gas action | Gas name | Purity |
| FID | Carrier gas | He or N2 | Not less than99.999% |
| TCD | Carrier gas | He,H2or N2 | Not less than99.999% |
| ECD | Carrier gas | N2 | Not less than99.999%(deoxidation) |
| FPD | Carrier gas | He or N2 | Not less than99.999% |
| Tail blowing | He or N2 | Not less than99.999% | |
| Combustion gas | H2 | Not less than99.999% | |
| Auxiliary gas | Air | Clean and dry as much as possible |
