• Model NO.：GE6022T
• Power Supply：220V
• Weight：0-50kg
• Certification：CE
• Customized：Non-Customized
• Temperature Range：0~100ºC
• Heating Rate：5ºC,S
• Cooling Rate：4ºC,S
• Uniformity：≤±0.2ºC
• Accuracy：≤±0.1ºC
•  Capacity：60×0.5ml
• Transport Package：Standard Carton Packing
• Specification：380mm×240mm×260mm (L×W×H)
• Trademark：WESTTUNE
• Origin：China
• HS Code：9027809990
• Production Capacity：1000

Basic Info.

Model NO. GE6022T Power Supply 220V Weight 0-50kg Certification CE Customized Non-Customized Temperature Range 0~100ºC Heating Rate 5ºC/S Cooling Rate 4ºC/S Uniformity ≤±0.2ºC Accuracy ≤±0.1ºC  Capacity 60×0.5ml Transport Package Standard Carton Packing Specification 380mm×240mm×260mm (L×W×H) Trademark WESTTUNE Origin China HS Code 9027809990 Production Capacity 1000

Product Description

GE6022T 60*0.5ml Gradient PCR thermal cycler
Gene-Explorer Touch series thermal cycler uses customized Marlow(US) peltier. Its max. ramping rate is 5 ºC/s and cycle times is more than 1000,000. The product combines a variety of advanced technologies: Windows system; color touch screen; independently controlled 4 temperature zones,; PC on-line function; printing function; big storage capacity and support USB device. All above functions allow PCR's excellent performance and meet higher experiment's need.



Key Features:

1) 8 pcs long service life Peltier heating units and form 4 circuits to control 4 temperature zones and allow double block gradient function;
2) Reinforced aluminum module with anodizing technology can keep rapid heating-conducting property and have enough corrosion resistance;
3) High heating and cooling rate, max. Ramping rate 5 ºC/s, can save your precious time;
4) Two blocks independently controlled and can run 2 different PCR programs simultaneously;
5) Stepless adjustable hot lid with pressure-protection, fit tubes of different heights to avoid tube melt and evaporation;
6) Windows interface, 8" ( 800×600, 16 colors) TFT color touch-screen with graphical display provides easy use for setting up and monitoring;
7) Built-in 11 standard program file template, can quickly edit the required files;
8) Folder management, user can build directory;
9) The running program and left time can be displayed in real time , allow to edit file when program is running;
10) One-click quick incubation function can meet experiment's needs such as denaturation, enzyme cutting/enzyme-link and ELISA;
11) Internal flash memory for 10000 typical PCR files in free configurable folders;
12) Hot lid temperature and hot lid work mode can be set to meet different experiment's need;
13) Automatic restart after power failure. When power is restored it can continue to run unfinished program;
14) GLP report records every step to provide accurate data support for experiment result analysis;
15) User Login Management, three-tier permission, password protection function to ensure data security;
16) Compatible with devices such as Mouse and Keyboard and capable to transfer data and perform software updates via USB Drive;
17) Support USB and LAN to update software;
18) One computer can control many sets of PCR via network connection;
19) Support email-alert function when experiment is over.


Specification:


Model	GE6022T
Capacity	60×0.5ml
Temperature Range	0~100ºC
Max. Heating Rate	5ºC/s
Max. Cooling Rate	4ºC/s
Uniformity	≤±0.2ºC
Accuracy	≤±0.1ºC
Display Resolution	0.1ºC
Temperature Control	BlockTube
Ramping Rate Adjustable	0.1~5ºC
Gradient Uniformity	≤±0.2ºC
Gradient Accuracy	≤±0.2ºC
Gradient Temp. Range	30~100ºC
Gradient Spread	1~30ºC
Hot Lid Temperature	30~110ºC
Hot Lid Height Adjustable	Stepless Adjustable
Number of Programs	1000 +(USB FLASH)
Max. No. of Step	30
Max. No. of Cycle	100
Time Increment/Decrement	1 Sec ~ 9 Min 59 Sec
Temp. Increment/Decrement	0.1~9.9ºC
Pause Function	Yes
Auto Data Protection	Yes
Hold at 4ºC	Forever
Print	Yes
LAN to computer	Yes
LCD	8inch,800×600 Pels, TFT
Communication	USB2.0 , LAN
Dimensions	380mm×240mm×260mm (L×W×H)
Weight	9kg
Power Supply	85~264VAC , 47~63Hz , 600 W

We also have other real time quantitive QPCR on sale, below are the hot selling models:
