GDSF-311WP Automatic SF6 Gas Dew Point Multifunctional Analyzer
HV Hipot Electric Co., Ltd.- After-sales Service：yes
- Warranty：1 year
- Measurement method：Resistive and Capacitive measurement principle
- Measurement range：dew point -80ºC--+20ºC(support ppmv)
- Accuracy：±1ºC
- Resolution：0.01ºC
Base Info
- Model NO.：GDSF-311WP
- Repeatability：± 0.5 ºC
- Gas flow：400-600ml,min
- Flow display：0-1000mL digital flow meter
- Sample gas pressure：≤1MPa
- Transport Package：Carton or Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan China
- HS Code：9027100090
- Production Capacity：3000PCS,Year
Description
SF6 Purity
Measurement method
Infrared technology.
Measuring range
0 ~ 100% SF6.
Accuracy and repeatability
± 0.5%, nothing to do with the flow.
Power supply
220VAC±10%, 50Hz, AC/DC use, over-charge protection, continuous working is no lower than 8hours.
Use environment temperature
-20--+60ºC
Environment humidity
90%RH
Measurement value influence
No effect of pressure and flow
Dimension
395*295*155mm
Weight
about 2kg
