• Model NO.：HT-LC700
• Type：Infrared Absorption Analyzer
• Test Principle：Infrared
• Transport Package：Cartoon Box
• Specification：140*215*140(mm)
• Trademark：HT
• Origin：China
• HS Code：9027100090
• Production Capacity：200 Pieces, Month

Basic Info.

Model NO. HT-LC700 Type Infrared Absorption Analyzer Test Principle Infrared Transport Package Cartoon Box Specification 140*215*140(mm) Trademark HT Origin China HS Code 9027100090 Production Capacity 200 Pieces/ Month

Product Description

Technical Specifications:
   Measurement Principle: Fuel cell (infrared principle optional, with different appearance)
   Display Mode: 320×240 dot matrix color LCD
   Measurement Range: 0~50PPm CO (range expandable)
   Measurement Accuracy: ≤±1.0%FS
   Resolution: 0.1PPm
   Repeatability: ≤±1.0%FS
   Response Time: T₉₀≤40S
   Output Port: 4-20mA (Non-isolated output, load resistance<1KΩ)
                        3 ways of programmable alarm output (Dry contact type, maximum load 220V/2A)
                        1 way of error alarm output
   Alarm: Sound and light alarm
   Communication Mode: RS485
   Power Supply: AC220V±10% 50/60Hz, power dissipation <10VA
   Environment Temperature: -10ºC~+50ºC
   Storage Environment Humidity: <90%RH, non-condensing
   Operation Environment Humidity: <100%RH, non-condensing
   Sample Gas Temperature: 0ºC~40ºC
   Sampling Mode: Gas in
   Sample Gas Flow: 400~600mL/min
   Gas Inlet Pressure: 5Kpa≤ relative pressure≤100Kpa (relief valve is recommended if the pressure >100Kpa)
   Gas Outlet Pressure: Free venting (under safe conditions)
   Size: 140mm×215mm×140mm (H×W×D)
   Installation Hole Size: 80mm×200mm (H×W)
   Sensor Service Life: >24 months (under normal conditions of use)
   Gas Circuit Port: NPT 1/8 internal thread
   Instrument Weight: Net weight 2.0Kg
   Installation Method: Embedded mounting

Features:
   a.   Menu can be switched between Chinese and English and the operation is intuitive and convenient;
   b.   320×240 graphic dot-matrix color LCD display is clear to see;
   c.   The original imported fuel cell sensor has a high measurement accuracy, rapid response speed, long calibration cycle and strong anti-interference capability, etc.;
   d.   Sound and light alarm function is equipped and the alarm limit is adjustable;
   e.   3 ways of alarm setting is equipped and alarm range is adjustable;
   f.    Temperature and pressure compensation could eliminate the impact of environment temperature and pressure changes on the measured value;
   g.   40 thousand pieces of historical data can be stored locally and read in list or exported through port;
   h.   RS485 communication port allows a bidirectional communication with computer according to users' needs;
   i.    Embedded mounting makes the installation easy and convenient.

Application:
  It can be used for on-line monitoring of carbon monoxide concentration in compressed air in automatic production line, spraying line and wood processing occasion.

Order Notice (Please indicate following messages when placing orders)
   Measurement range
   Measured gas pressure
   Background gas composition
