• Model NO.：HT-TA530
• Type：Ion Current
• Test Principle：Limiting Current
• Transport Package：Cartoon Box
• Specification：29*75*162(mm)
• Trademark：HT
• Origin：China
• HS Code：9027100090
• Production Capacity：200 Pieces, Month

Basic Info.

Model NO. HT-TA530 Type Ion Current Test Principle Limiting Current Transport Package Cartoon Box Specification 29*75*162(mm) Trademark HT Origin China HS Code 9027100090 Production Capacity 200 Pieces/ Month

Product Description

Technical Specifications:
   Measurement Principle: Ion current (limiting current)
   Display Mode: External display module (optional)
   Measurement Range: 10.00%~98.00% O₂
   Measurement Accuracy: ≤±1.5%FS
   Resolution: 0.01%
   Repeatability: ≤±1.0%FS
   Response Time: T₉₀≤30S
   Output Port: 4-20mA.DC (Non-isolated output, load resistance<Ω)
                        1 way of programmable alarm output (Dry contact type, maximum load 220V/2A)
                        Display module port
   Power Supply: DC24V±10%, 1A
   Environment Temperature: -10ºC~+50ºC
   Storage Environment Humidity: <90%RH, non-condensing
   Operation Environment Humidity: <100%RH, non-condensing
   Sample Gas Temperature: 0ºC~50ºC
   Sampling Mode: Gas in
   Gas Inlet Pressure: Stable pressure (control the pressure within the recommended limits to make sure the flow is within 400~600mL/min)
   Gas Outlet Pressure: Free venting (under safe conditions)
   Background Gas: N₂ or other inert gas
   Size: 29mm×75mm×162mm (H×W×D)
   Sensor Service Life: >4 years (under normal conditions of use)
   Gas Circuit Port: Φ6 plastic tube fitting
   Installation Method: Wall mounting

Features:
   a.   The original imported limiting current sensor consumes no service life when the power is off, and has a long service life, rapid response speed, and high measurement accuracy, long calibration cycle and is easy to maintain, etc.;
   b.   The instrument allows multi-point fractional liner calibration, satisfying the need for an accurate measurement of oxygen content among the full range.
   c.   Automatic temperature compensation function could eliminate the impact of environmental temperature changes on the measurement accuracy;
   d.   Measurement range is 10.00%~98.00%O₂;
   e.   No calibration gas is needed and the instrument is not affected by the oxygen content in the operation environment;
   f.    The analyzer has one way of programmable 4-20mA analog output;
   g.   Display module can be equipped (optional).

Application:
   It is widely used in the real-time detection and analysis of high concentration oxygen in medical and industrial oxygenerator, smelting industry, medical and health care, petrochemical industry, environmental protection, electronic power and other industries.

Order Notice (Please indicate following messages when placing orders)
   Measurement range
   Measured gas pressure
   Background gas composition
