• Model NO.：CY-HT-PG201
• Display Mode：128X64 Matrix DOT LCD
• Repeatability：≤± 1%
• Sampling Mode：Sample Gas Pass-in or Extraction
• Sample Gas Temperature：-10ºC ~ 50ºC
• Sample Gas Flow：300 ~ 600ml,Min
• Install Mode：Portable Mode
• Transport Package：Wooden Case
• Specification：155mmx260mmx340mm
• Trademark：CYKY
• Origin：Zhengzhou, China
• Production Capacity：100pieces,Month

Basic Info.

Model NO. CY-HT-PG201 Display Mode 128X64 Matrix DOT LCD  Repeatability ≤± 1% Sampling Mode Sample Gas Pass-in or Extraction Sample Gas Temperature -10ºC ~ 50ºC Sample Gas Flow 300 ~ 600ml/Min Install Mode Portable Mode Transport Package Wooden Case Specification 155mmx260mmx340mm Trademark CYKY Origin Zhengzhou, China Production Capacity 100pieces/Month

Product Description

Portable Infrared Carbon Dioxide Analyzer
Application of infrared Carbon Dioxide Analyzer:
Only for welding and cutting proportional gas.

Instrument features of infrared Carbon Dioxide Analyzer:
• Friendly communication menu makes the operation visual and simple;
• Based on the infrared absorption principle, there is no abrasion on the measurement part thus there is no need to maintain the analyzer;
• It is of good selectivity to the tested gas;
• Long calibration interval cycle, high accuracy and reliable stability;
• There is no need to do special test and protection to the sensor within test range, making the operation and maintaining easier;
• The compensation system for temperature can eliminate the change from environment temperature;
• The function of storing data automatically allows the users to look through the historic data freely;
• The built-in lithium battery with large capacity is convenient for field operation and easy to maintain;
• The built-in extraction pump(optional).

Technical parameters of infrared Carbon Dioxide Analyzer:

Test principle	infrared principle
Display mode	128×64 matrix dot LCD
Test range	0 ~ 30/50/99.9% CO2
Accuracy	≤± 1.2%FS
Repeatability	≤± 1%
Response time	T90≤15S
Sample gas temperature	-10ºC ~ 50ºC
Sample gas flow	300 ~ 600ml/min
Sampling mode	sample gas pass-in or extraction
Sample gas pressure(without pump)	0.05Mpa≤entrance displayed pressure≤ 0.35Mpa,steady pressure environment
Sample gas pressure(with pump)	micro-positive pressure, micro-negative pressure or  ordinary pressure
Appearance Size	155mm×260mm×340mm(H×W×D)
Serving life	>24 months (under normal use)
Gas circuit port	NPT 1/8 internal thread
Battery specification	lithium battery,11000mAH ,12.6V/2Ah
Charging source	AC170 ~ 264V  50/60Hz
Install mode	portable mode
