ASTM D139 Floating Tester for Asphalt

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Power：Electronic
  • Usage：Bitumen Float Test
  • Function：Determining The Consistency of Bitumen
  • Test Method：ASTM D139
  • Water in The Bath：28 L
  • Total Power Consumption：Not More Than 2000 W

Base Info

  • Model NO.：GD-0631
  • Warranty：1 Year
  • Transport Package：Plywood Case for Gd-0631
  • Specification：750*540*580 mm
  • Trademark：GOLD
  • Origin：Chongqing, China (Mainland)
  • HS Code：9014800090
  • Production Capacity：100 Set,Sets Per Month

Description

1Power supplyAC220V(-5%~+10%),50Hz2Bath size370mm×300mm×300mm3Suitable water28L4Heating unitElectric heater,power 1500W5Cooling unitNew type refrigeration compressor6Temperature control range5ºC~80ºC7Temperature control precision±0.1ºC8Float diskThickness 1.4mm±0.1mm,weight 37.9g±0.2g9Copper tubeThickness 1.4mm±0.1mm,weight 9.8g±0.2g10Ambient temperature≤30ºC11Relative humidity≤85%12Maximum power consumption2000W13Dimension750mm×540mm×580mm14Net weight30kg
