• Model NO.：HT-TA025
• Type：Electrochemical Gas Analyzer
• Test Principle：Fuel Cell
• Transport Package：Cartoon Box
• Specification：82*38*157(mm)
• Trademark：HT
• Origin：China
• HS Code：9027100090
• Production Capacity：200 Pieces, Month

Basic Info.

Model NO. HT-TA025 Type Electrochemical Gas Analyzer Test Principle Fuel Cell Transport Package Cartoon Box Specification 82*38*157(mm) Trademark HT Origin China HS Code 9027100090 Production Capacity 200 Pieces/ Month

Product Description

Technical Specifications:
   Measurement Principle: fuel cell
   Display Mode: LCD display with high resolution
   Measurement Range:0~10/100/1000PPm O₂
   Measurement Accuracy: 0~1000PPm≤±1%FS
                                           0~100PPm≤±2%FS
                                           0~10PPm≤±3%FS
   Resolution: 0.1PPm
   Repeatability: ≤±1.0%FS
   Response Time: T₉₀≤60S
   Output Port: 4-20mA.DC (Non-isolated output, load resistance<1KΩ)
   Communication Mode: RS485
   Power Supply: DC24V±10%, 200mA
   Environment Temperature: -10ºC~+50ºC
   Storage Environment Humidity: <90%RH, non-condensing
   Operation Environment Humidity: <100%RH, non-condensing
   Sample Gas Temperature: 0ºC~40ºC
   Sampling Mode: Free diffusion (other mode can be customized)
   Sample Gas Pressure: Relative pressure ±5kPa, stable pressure
   Background Gas: Inert, acid and reducing gas, etc.
   Sensor Service Life: >24 months (under normal conditions of use)
   Gas Circuit Port: NPT1/8 Internal Thread for protection and calibration cover
   Installation Method: KF40 flanged mounting


Features:
   a.   The instrument has a small and nice look, a unique structure and design;
   b.   The LCD display with high resolution is clear;
   c.   The original imported fuel cell sensor has a high measurement accuracy, rapid response speed, long calibration cycle and strong anti-interference capability, etc.;
   d.   The instrument allows multi-point fractional liner calibration, satisfying the need for an accurate measurement of oxygen content among the full range;
   e.   The menu lock function could prevent mis-operation, which may change instrument parameters and affect its performance;
   f.    Automatic temperature compensation function could eliminate the impact of environmental temperature changes on the measurement accuracy;
   g.   KF40 flanged mounting makes it easier to change the oxygen sensor.

Application:
   The instrument is special for glove box, but it can also be used for gas measurement of protection pipe under normal pressure.

Order Notice (Please indicate following messages when placing orders)
   Measured gas pressure
   Background gas composition


       Jiuyin Technology Chengdu Co., Ltd. is a high-tech enterprise with more than 10 years of experience in the gas analysis industry, specializing in the research, development, production and sales of gas analysis instruments and systems, with a certain scale and comprehensive strength. Our company has always adhered to the development strategy of innovation and fully relied on the advantages of human resources to provide customers with products with high efficiency, high reliability and high cost performance.

       Since its establishment, the company has given full play to its own advantages, perfected its sales network, paid attention to its corporate image, followed the management concept of " technology forerunner", actively adopted international advanced technology, and possessed stable and excellent suppliers, partners and customer resources, which can provide customers with high performance-price ratio analysis instruments, analysis modules, pretreatment components, gas analysis systems and other services.

       The main products are: oxygen analyzer, dew point meter, humidity meter,gas chromatograph and other 9 categories, 16 series and 100 balance products, which are widely used in scientific research, environmental protection, energy-saving transformation, metallurgy, building materials, chemical industry, petroleum, power plant, pharmaceutical and food industries and other fields. The company has obtained ISO9001 quality management system certification, 20+ national patents and 20+ computer software copyright certificates, and was certified as a high-tech enterprise in September 2018, continuously developing high-tech products suitable for customers' site with outstanding service quality and continuously innovative technical service strength.

       The company now has an experienced technical support team to provide users with 24 / 7 technical support to solve the user's on-site debugging and use problems as soon as possible.

       Jiuyin Technology Chengdu Co., Ltd. sincerely welcomes friends from all walks of life at home and abroad to come to negotiate business and patronize guidance.
