• Model NO.：TPJ-26
• Specification：ISO
• Trademark：TOP
• Origin：Zhejiang
• Production Capacity：1000PCS,Month

Basic Info.

Model NO. TPJ-26 Specification ISO Trademark TOP Origin Zhejiang Production Capacity 1000PCS/Month

Product Description

Name: Carbon Dioxide Recorder

Model: TPJ-26, TPJ-26-I

Two color for optional: blue and orange




Introduction

Can manually open the switch, set up the date by prompt, manual or automatic mode, if you choose manual mode, press the button each time and the data is recorded. Can record the time and some parameters (like temperature, moisture, Light, CO2, etc. ). If you choose automatic mode, we should set a good time interval (1-5 hours), the equipment can be set in accordance with good spacing and record data automatically. After the data collection, can press the stop button, you can view historical data on the mainframe, the computer can also be downloaded and automatically demonstrate the form curves and graphics. Software can print and data processing.

Characteristics

Ø  Large LCD display, touch key, smart and portable, easy to operate.
Ø  One-button switch, can record both manually and automatically.
Ø  Can connect with computer to upload, process, backup datum.
Ø  Both AC and DC available, 3.7v 4Ah Li-ion battery, with charging protection, Low voltage protection. Suitable for field detecting as well.
Ø  With GPS position function, be able to define coordinates real-time. (optional function)
Ø  With powerful data storage function with flash storage, can store the latest 30,000 records, and also standard configured 4G SD card
Ø  Datum saved in machine won't lose when power off.
Ø  Computer software has powerful data processing functions.
Ø  Probes have the uniformity; different probes can be connected to any of the sensor interface.
Ø  With 32 channels, test at the same time, probes are unlimited in the range of capacity.
Ø  RS485 communication, the cable can be up to 100meters
Ø  Can choose testing parameters by you according to needs. Sampling interval time of each sensor can be set separately.
Ø  Low power consumption.
Ø With GPS positioning function,global real-time positioning and navigation
Ø Equipped with TF Card,with GPRS function, but need to configure SIM card by yourself


Handset technical parameters:
Record capacity:   flash storage your latest 30,000 records, with 4G SD card
Record time interval:   5 s-90 hr continuously adjustable.
Sensor communication:  RS485
Computer communication:   USB1.1
Power:  3.7V Li-Ion battery, 5V/2A power source adapter

Technical parameter

Measuring range: 0-2000ppm
Resolution: 1ppm
Accuracy: ± (50ppm+results x 3%)
Record time interval: 5 seconds -90 hours continuously adjustable
Stability: <30ppm/y

Model

Model	Function difference
TPJ-26	Max test range: 2000PPM
TPJ-26-I	Max test range: 5000PPM
