Portable Color Difference Meter Sc20 Doing Color Analysis and Color Controling
Sino Age Development Technology- Usage：Color Analysis and Color Controlling
- Light Source：C Light Source
- Communication Interface：USB
- Weight (G)：204
- Dimension (Mm)：171X50X49
- Transport Package：Delivery Package: Carton
Base Info
- Model NO.：SC20
- Specification：CE, SGS
- Trademark：SADT
- Origin：China
- HS Code：90318090
- Production Capacity：500 Pieces,Month
Description
Basic Info.
Model NO. SC20 Specification CE, SGS Trademark SADT Origin China HS Code 90318090 Production Capacity 500 Pieces/MonthProduct Description
Precise Color Reader SC20 Details:SC20 portable color difference meter is widely applied to quality control of plastic and printing industries.
It makes you capture color efficiently and accurately.
KEY FEATURES:
Easy operation makes you use it easily.
Widely applied to quality control of plastic and printing industries.
Display directly color difference by E*ab, L*a*b, CIE_L*a*b, CIE_L*c*h.
Standard deviation within E*ab0.2 (test condition: Choose average values by 12 pcs white tabula).
I t can be connected with computer to do the inspec tion by sof tware with USB expansion interface.
| Model | SC20 |
| Accuracy | <0.2 ΔE*ab |
| Display | Δ E*ab, CIE_Lab, ΔLab, CIE_Lch |
| Light source | C light source |
| Test range | L: 0~100, a: -128~127, b: -128~127 |
| Test time | About 3 seconds |
| Test interval | 2 seconds |
| Sensor | Silicon photodiode array |
| Working environment | 0~40oC, < 85%RH |
| Aperture (mm) | Ø8 |
| Power supply | DC/5V (1.5A)/2 x 1.5V (AAA) battery |
| Weight (g) | 204 |
| Dimension (mm) | 171x50x49 |
