• Model NO.：SC30,SC50
• HS Code：9031809090
• Production Capacity：50 Piece,Pieces , Week

Basic Info.

Model NO. SC30/SC50 HS Code 9031809090 Production Capacity 50 Piece/Pieces / Week

Product Description

Portable Digital Color Reader/Colorimeter Sc30/Sc50

Portable Color Difference Meter/colorimeter SC30
Portable digital Color reader/colorimeter SC30

Introduction
SC50/SC30 is developed according to international CIE1931, 1976 and other relevant standards and national standards, it is a new economic and practical general colorimeter equipped with the latest imported LED light source and sensor, which make it stable, durable, and economy. The menu-oriented interface that makes operation simple and easy to understand. SC50/ SC30 is not only widely used on Quality department about the color difference, but also used on the school teaching, scientific research, and color design.


Key Features
Button & menu operation, easy to understand, reasonable price.
Commonly used of two measurement modes: Lab&Lch, easy to switch measurement.
Automatically display the color difference between the sample and standard sample, also display the color trend degree.
Prac tical of the average measurement mode, uneven sur face also can measure.
The color difference sof tware can analysis, exchange the color difference graph and data.
The optional Micro-printer can output the color difference data in time.


Specifications

Model	SC50	SC30
Accuracy	Standard deviation:within  delta   E*ab: <0.08 ( When the white calibration plates is measured 30 times, and averaged)	Standard deviation:within  delta   E*ab:0.1 ( When the white calibration plates is measured 30 times, and averaged)
Illumination Light system	45/0	45/0
Inspection angle	10 ° / 2°	10 °
Inspection conditions	D65 / C / F11 / D50	D65
Measurement model	Single mode, Average mode	Single mode, Average mode
Storage	50 groups of standard samples, 30 groups of values for each sample	12 groups of standard samples, 30 groups of values for each sample
Display	L*a*b*, L*C*H*, Yxy,  delta  E*ab,  delta  (L*a*b*),  delta (L*C*H*),  delta  Yxy	L*a*b*, L*C*H*, delta E*ab,  delta  (L*a*b*),  delta  (L*C*H*)
Language	English / Chinese	English / Chinese
Measurement Aperture	Ø8mm	Ø8mm
Power supply	4 AA-size battery or AC adapter	4 AA-size battery or AC adapter
Working environment	0-40 °  C(32-104 °  F), Relative humidity 85% or less	0-40 °  C(32-104 °  F), Relative humidity 85% or less
Weight (g)	330(without batteries)	310(without batteries)
Dimension (mm)	110x60x190	110x60x190
