Portable Digital Roughscan Surface Roughness Tester
Sino Age Development Technology- Delivery：Within 10 Workdays Upon Receipt of Full Payment
- Transport Package：Carton
- Specification：SGS
- Trademark：SADT
- Origin：China
Base Info
- Model NO.：RoughScan
- HS Code：9031809090
- Production Capacity：50 Piece,Pieces , Week
Description
Basic Info.
Model NO. RoughScan HS Code 9031809090 Production Capacity 50 Piece/Pieces / WeekProduct Description
Surface Roughness Tester RoughScanPortable Digital RoughScan Surface Roughness Tester
RoughScan is a portable, batterypowered, micro processed instrument for checking surface roughness with digital readout on LCD. RoughScan surface roughness tester can be widely used in laboratory, inspection area in the shop, or wherever on-suit surface roughness testing is required.
| Model | RoughScan |
| Display | 3-digit LCD |
| Measuring range | Ra(ISO): 0.03μ m-6.3μ m/1μ " -250μ " Rz(DIN): 0.2μ m-25.0μ m/8μ " -999μ " Ry/Rmax(ISO): 0.2μ m~250μ m/8μ " ~999μ " |
| Resolution | 0.01μ m/1μ " |
| Accuracy | conform ISO and DIN standards |
| Uncertainty | ≤ 2% |
| Cut-off(l ) | 0.8mm/0.30" , ANSI 2RC Filter |
| Power | 9-volt alkaline battery |
| Battery capacity | approx. 3000 measurements |
| Probe type | piezo-electric |
| Maximum stylus force | 15.0mN / 1500mgf |
| Operating temperature | 10° C~45° C / 50° F~113° F |
| Storage temperature | 0° C~60° C / 32° F~147° F |
