Spectrum Analyzer
Shanghai Total Industrial Co., Ltd.- Transport Package：Carton
- Trademark：ShowRange
- Origin：Shanghai
Base Info
- Model NO.：srs2000 series, SRS3030, SRS3030D
- Production Capacity：5000
Description
| Specification | SRS3030D |
| Spectrum Measurement | |
| Range | 9kHz - 3GHz |
| Resolution | 1Hz |
| Accuracy |
±(Frequency Marker Readout*Frequency Reference Accuracy +1%*Span +10%*RBW+0.5*[Span/(Sweep Points-1) ]+1Hz) |
| Internal Reference(10MHz) | Aging Rate < 1ppm/year; Stability Over Temperature < 0.5ppm(15C ~ 35C) |
| Resolution Bandwidth (RBW) | |
| Range | Range (<1kHz Optional): 10Hz~500kHz(1-10 Sequence), 1MHz, 3MHz |
| Electability(60dB/3dB) |
RBW≤500kHz; <5:1 Typical (Digital implementation,next to Gaussian shape); <5% Typical |
| Accuracy | RBW≤500kHz; < 5%, Typical |
| Video Bandwidth | 10Hz~3MHz, 1-3-10 Sequence |
| Average Noise Level (10Hz RBW, 0dB RF Attenuator) | |
| 100kHz - 1MHz | <-90dBm-3×(f/100kHz)dB |
| 100kHz - 10MHz | <-120dBm |
| 10MHz - 1GHz | <-122dBm |
| 1GHz - 3GHz | <-120dBm |
| Phase Noise | |
| Offset 10kHz | -85dBc/Hz |
| Offset 1MHz | -115dBc/Hz |
| Sweep Time | |
| Span (100Hz≤SPAN≤3GHz) | 10ms to 3000s |
| Zero Span | 1ms to 3000s |
| Sweep Modes | Continuous, Single |
| Trigger | |
| Trigger Source | AUTO, Video, EXT |
| Offset 100kHz | 5V TTL Level (Typical) |
| Frequency Counter | |
| Resolution | 1Hz, 10Hz, 100Hz, 1kHz |
| Uncertainty | Frequency Readout x Frequency Reference Progress+Counter Resolution |
| Amplitude Accuracy (20C~30C) | |
| Overall Amplitude Accuracy(90%) |
±1.5dB Input Signal Range: -50dBm ~ 0dBm |
| Amplitude | |
| Max. Safe Input Level | Average Continuous Power: +33dBm |
| Max. Input DC Voltage | 50Vdc |
| Input Attenuator Range | 0~50B, in 1dB step |
| 1dB Compression | +13dBm |
| Stray and Residual Response | |
| Third-Order Intercept(TOI) | >30MHz: +10dBm |
| Second Harmonic Intercept(SHI) | +30dBm |
| Input Related Spurious | <-60dBm |
| Residual Response | <-85dBm |
| Tracking Generator | |
| Frequency Range | 100kHz to 3GHz |
| Output Power |
-30dBm ~ 0dBm, in 1dB step |
| Output Flatness | ±3dB |
| Input/Output | |
| RF Input | N Type, Female(50Ω) |
| USB | USB Host, USB Device |
| LAN | 10/100 Base-T, RJ-45 Connector |
| RS-232 | 9 Pin D-SUB (Positive) |
| AM/FM Demodulation | Headset |
| Reference Input/Output | 10MHz, BNC Negative, Input: 0dBm ~ +10dBm; Ouput: 0dBm±2dB |
| VGA | 640*480, 60Hz,15 Pin, D-SUB (Negative) |
| General Characteristics | |
| Internal Memory | 256MB |
| Power | Input Voltage: 110VAC / 220VAC; Frequency: 40Hz - 60Hz; Max Consumption: 60W |
| Display | 8.4 Inches TFT LCD, 640×480 |
| Product Color | White and Gray |
| Product Net Weight | 8.6 Kg |
| Product Size | 390mm(W) × 182mm(H) ×230mm(D) |
| Standard Accessories | Power Cord, N/SMA Convertor, N/BNC Convertor, RF Cable, Antenna |
| Standard Individual Packing | Gift Box, English Manual |
| Standard Quantity Per Carton | 1 PC |
| Standard Carton Measurement | |
| Standard Carton Cross Weight | |
| Optional Accessories* | USB-GPIB |
| Specification | SRS2010 |
| Spectrum Measurement | |
| Range | 9kHz - 1GHz |
| Resolution | 1Hz |
| Accuracy |
±(Frequency Marker Readout*Frequency Reference Accuracy +1%*Span +10%*RBW+0.5*[Span/(Sweep Points-1)]+1Hz) |
| Internal Reference(10MHz) |
Aging Rate <1ppm/year; Stability Over Temperature < 0.5ppm (15C ~ 35C) |
| Resolution Bandwidth (RBW) | |
| Range | 10Hz~500kHz (1-10 Sequence), 1MHz, 3MHz |
| Electability(60dB/3dB) |
RBW≤500kHz; < 5:1 Typical (Digital implementation, next to Gaussian shape); < 5% Typical |
| Accuracy | RBW≤500kHz; < 5%, Typical |
| Video Bandwidth | 10Hz~3MHz, 1-3-10 Sequence |
| Average Noise Level (10Hz RBW, 0dB RF Attenuator) | |
| Preamplifier Off |
100kHz/-90dBm,1MHz/-125dBm,100MHz/-122dBm,500MHz/-122dBm,1000MHz/-120dBm, 1.4GHz/-118dBm,1.8GHz/-115dBm,2.2GHz/-121dBm,2.5GHz/-121dBm,3.0GHz/-120dBm |
| Preamplifier On |
100kHz/-139dBm,1MHz/-130dBm,100MHz/-140dBm,500MHz/-135dBm,1000MHz/-133dBm, 1.4GHz/-134dBm,1.8GHz/-130dBm,2.2GHz/-138dBm,2.5GHz/-138dBm,3.0GHz/-137dBm |
| Phase Noise | |
| Offset 10kHz | -80dBc/Hz |
| Offset 30kHz | -90dBc/Hz |
| Offset 1MHz | -115dBc/Hz |
| Sweep Time | |
| Span (100Hz ≤ SPAN ≤ 3GHz) | 10ms to 3000s |
| Zero Span | 1ms to 3000s |
| Sweep Modes | Continuous, Single |
| Trigger | |
| Trigger Source | AUTO, Video, EXT |
| Offset 100kHz | 5V TTL Level (Typical ) |
| Frequency Counter | |
| Resolution | 1Hz, 10Hz, 100Hz, 1kHz |
| Uncertainty | Frequency Readout x Frequency Reference Progress + Counter Resolution |
| Amplitude Accuracy (20C~30C) | |
| Overall Amplitude Accuracy(90%) | ±1.2dB; Input Signal Range: -50dBm ~ 0dBm |
| Amplitude | |
| Max. Safe Input Level | Average Continuous Power: +23dBm |
| Max. Input DC Voltage | 50Vdc |
| Input Attenuator Range | 0~30B, in 1dB step |
| 1dB Compression | +7dBm |
| Stray and Residual Response | |
| Third-Order Intercept(TOI) | >30MHz: +13dBm |
| Second Harmonic Intercept(SHI) | +30dBm |
| Input Related Spurious | < -60dBm |
| Residual Response | < -85dBm |
| Input/Output | |
| RF Input | SMA Type, Female (50Ω) |
| USB | USB Host, USB Device |
| LAN | 10/100 Base-T, RJ-45 Connector |
| RS-232 | 9 Pin D-SUB (Positive) |
| AM/FM Demodulation | Headset |
| Reference Input/Output |
10MHz, BNC Negative, Input: 0dBm ~ +10dBm; Ouput: 0dBm±2dB |
| VGA | 640*480,60Hz,15 Pin, D-SUB (Negative) |
| General Characteristics | |
| Internal Memory | 128MB |
| Power |
Input Voltage: 110VAC (Optional), 220VAC; Frequency: 40Hz - 60Hz; Max Consumption: 35W |
| Display | 6.5 Inches TFT LCD, 640×480 |
| Product Color | White and Gray |
| Product Net Weight | 3.0 Kg |
| Product Size | 330mm(W) × 163mm(H) ×165mm(D) |
| Standard Accessories | Power Cord, N/SMA Convertor, N/BNC Convertor, RF Cable, Antenna |
| Standard Individual Packing | Gift Box, English Manua |
| Standard Quantity Per Carton | 1 PC |
| Standard Carton Measurement | 350mm(W) × 180mm(H) ×170mm(D) |
| Standard Carton Cross Weight | 4 Kg |
| Optional Accessories* | USB-GPIB |
| Specification | SRS2020D |
| Spectrum Measurement | |
| Range | 9kHz - 2GHz |
| Resolution | 1Hz |
| Accuracy |
±(Frequency Marker Readout*Frequency Reference Accuracy +1%*Span +10%*RBW+0.5*[Span/(Sweep Points-1) ]+1Hz) |
| Internal Reference(10MHz) | Aging Rate < 1ppm/year; Stability Over Temperature < 0.5ppm(15C ~ 35C) |
| Resolution Bandwidth (RBW) | |
| Range | 10Hz~500kHz(1-10 Sequence), 1MHz, 3MHz |
| Electability (60dB/3dB) |
RBW ≤ 500kHz; <5:1 Typical (Digital implementation, next to Gaussian shape); <5% Typical |
| Accuracy | RBW ≤ 500kHz; < 5%, Typical |
| Video Bandwidth | 10Hz~3MHz, 1-3-10 Sequence |
| Average Noise Level (10Hz RBW, 0dB RF Attenuator) | |
| Preamplifier Off |
100kHz/-90dBm,1MHz/-125dBm,100MHz/-122dBm,500MHz/-122dBm,1000MHz/-120dBm, 1.4GHz/-118dBm,1.8GHz/-115dBm,2.2GHz/-121dBm,2.5GHz/-121dBm,3.0GHz/-120dBm |
| Preamplifier On |
100kHz/-139dBm,1MHz/-130dBm,100MHz/-140dBm,500MHz/-135dBm,1000MHz/-133dBm, 1.4GHz/-134dBm,1.8GHz/-130dBm,2.2GHz/-138dBm,2.5GHz/-138dBm,3.0GHz/-137dBm |
| Phase Noise | |
| Offset 10kHz | -80dBc/Hz |
| Offset 30kHz | -90dBc/Hz |
| Offset 1MHz | -115dBc/Hz |
| Sweep Time | |
| Span (100Hz≤SPAN≤3GHz) | 10ms to 3000s |
| Zero Span | 1ms to 3000s |
| Sweep Modes | Continuous, Single |
| Trigger | |
| Trigger Source | AUTO, Video, EXT |
| Offset 100kHz | 5V TTL Level (Typical) |
| Frequency Counter | |
| Resolution | 1Hz, 10Hz, 100Hz, 1kHz |
| Uncertainty | Frequency Readout x Frequency Reference Progress+Counter Resolution |
| Amplitude Accuracy (20C~30C) | |
| Overall Amplitude Accuracy(90%) | ±1.5dB; Input Signal Range: -50dBm ~ 0dBm |
| Amplitude | |
| Max. Safe Input Level | Average Continuous Power: +23dBm |
| Max. Input DC Voltage | 50Vdc |
| Input Attenuator Range | 0~30B, in 1dB step |
| 1dB Compression | +7dBm |
| Stray and Residual Response | |
| Third-Order Intercept(TOI) | >30MHz: +13dBm |
| Second Harmonic Intercept(SHI) | +30dBm |
| Input Related Spurious | <-60dBm |
| Residual Response | <-85dBm |
| Tracking Generator | |
| Frequency Range | 100kHz to 1.8GHz |
| Output Power | -30dBm ~ 0dBm; in 1dB step |
| Output Flatness | ±3dB |
| Input/Output | |
| RF Input | SMA Type, Female(50Ω) |
| USB | USB Host, USB Device |
| LAN | 10/100 Base-T, RJ-45 Connector |
| RS-232 | 9 Pin D-SUB (Positive) |
| AM/FM Demodulation | Headset |
| Reference Input/Output | 10MHz, BNC Negative, Input: 0dBm ~ +10dBm; Ouput: 0dBm±2dB |
| VGA | 640*480,60Hz,15 Pin, D-SUB(Negative) |
| General Characteristics | |
| Internal Memory | 128MB |
| Power | Input Voltage: 110VAC(Optional) , 220VAC; Frequency: 40Hz - 60Hz; Max Consumption: 35W |
| Display | 6.5 Inches TFT LCD, 640×480 |
| Product Color | White and Gray |
| Product Net Weight | 3.0 Kg |
| Product Size | 330mm(W) × 163mm(H) ×165mm(D) |
| Standard Accessories | Power Cord, N/SMA Convertor, N/BNC Convertor, RF Cable, Antenna |
| Standard Individual Packing | Gift Box, English Manual |
| Standard Quantity Per Carton | 1 PC |
| Standard Carton Measurement | 350mm(W) × 180mm(H) ×170mm(D) |
| Standard Carton Cross Weight | 4.0 Kg |
| Optional Accessories* | USB-GPIB |
