Semi-Automat Distillation Kjeldahl Nitrogen Analyzer
Zhejiang Top Cloud-Agri Technology Co., Ltd.- Type：Electrochemical Gas Analyzer
- Delivery Time：in 10 Days After Receiving Payment
- Working Mode：Semi-Automatic
- Power：220V,50Hz, 1000W
- Shape Size：380*320*670mm
- Weight：20kg
Base Info
- Model NO.：KDN
- Transport Package：in Cartoon
- Specification：ISO
- Trademark：TOP
- Origin：Zhejiang
- HS Code：9031809090
- Production Capacity：200PCS,Month
Description
Characteristics
1. Adopt microcomputer controlling process
2. Automatically control distills, add water, control water level, and cut off the water supply
3. Various security protections: Digestive system security device, steam generator water shortage alarm, water level detection fault alarm
4. Instrument shell adopts specially made plastic spray steel; Working area adopts ABS anticorrosive board. Avoid chemical reagent corrosion and mechanical surface damage, acid-proof and alkali proof.
5. Once detected fault, the controlling system will power off automatically
6. Adopt tap water source, wide adaptability, and requirement for the test is low
Technical parameters
Measuring varieties: Grain, feed, food, dairy products, drink, soil, medicine, precipitate, chemicals and so on
Working mode: Semi-automatic
Water-in mode: Tap water and distilled water
Sample quantity: Solid: 0.20g-2.00g,
Semisolid: 2.00g-5.00g
Liquid: 10.00ml-25.00ml
Measuring range: 0.1mgN-200mgN (mg nitrogen)
Recovery rate: ≥ 99% (relative error, including digestive process)
Distillation speed: 5-15 min/sample (according to sample amount)
Cooling water consumption: digestion:5L/min
distillation:3L/min
Repetition rate: Relative standard deviation <± 1%
Power: AV 220V/50Hz, 1000W
Water supply: Water pressure >1.5MPa
Water temperature<20° C
Shape size: 380*320*670mm
Weight: 20Kg
Model different
| Model | Function difference |
| KDN-04C | Tap water source; with 4 holes digital digest furnace |
| KDN-08C | Tap water source; with 8 holes digital digest furnace |
| KDN-20C | Tap water source; with 20 holes digital digest furnace |
