• Model NO.：SY-265G
• Specification：SGS
• Trademark：SAMYON
• Origin：Cn
• HS Code：903180
• Production Capacity：100sets Per Month

1. Power supplyAC 220V±10%, 50 Hz2. Heating deviceElectric heater, 600 W3. Refrigeration equipmentDouble refrigeration compressors4. Stirring motor6 W, 1200 RPM5. Temperature rangeRoom temperature~-70 ºC6. Temperature control accuracy±0.1 ºC7. Constant temperature bath5.8 L, stainless steel.8. Ambient temperature≤30 ºC9. Relative humidity≤85%10. Temperature sensorPt100.11. Illumination220 V electricity-saving lamp.12. Capillary viscometer tubes(Pinkevitch viscometer)7 pieces in total. The diameters for each is 0.6, 0.8, 1.0, 1.2, 1.5, 2.0, 2.5 mm.13. Maximum power consumption1700 W14. Dimension530mm×460mm×870mm
1. Power supply: AC 220V±10%, 50 Hz
2. Heating device: Electric heater, 600 W
3. Refrigeration equipment: Double refrigeration compressors
4. Stirring motor: 6 W, 1200 RPM
5. Temperature range: Room temperature~-70 ºC
6. Temperature control accuracy: ±0.1 ºC
7. Constant temperature bath: 5.8 L, stainless steel.
8. Ambient temperature: ≤30 ºC
9. Relative humidity: ≤85%
10. Temperature sensor: Pt100.
11. Illumination: 220 V electricity-saving lamp.
12. Capillary viscometer tubes(Pinkevitch viscometer): 7 pieces in total. The diameters for each is 0.6, 0.8, 1.0, 1.2, 1.5, 2.0, 2.5 mm.
13. Maximum power consumption: 1700 W
14. Dimension: 530mm×460mm×870mm
