• Model NO.：Gm60
• HS Code：9031809090
• Production Capacity：50 Piece,Pieces , Week

ModelGMSGM60ApplicationPainting, printing, floor material, plastic, ceramics, leather, hardware, plating.Measuring Range(Gu)0~120, 120~2000 @ 20°
0~120, 120~1000 @ 60°
0~120, 120~160 @ 85°0~120, 120~1000 @ 60°Readout Error(Gu)±1.5 (0~120)
±1.5%(120~2000)±1.5 (0~120)
±1.5%(120~1000)Repeatability±0.5 (0~120)
±0.5%(120~2000)±0.5 (0~120)
±0.5%(120~1000)Aperture (mm)20°, 60°, 85°60°Measurement Spot (mm)10×10 @ 20°
9×15 @ 60°
5×38 @ 85°9×15Memory900 data or 30 groups, CF card (optional)InterfaceUSB / printer /Bluetooth (Bluetooth is only avalaible for GMS)SoftwareData managing softwarePower Supply+5V, AA*4Working Environment10~40ºC, <85%RH,Dimension (mm)164×58×88Net Weight(g)520StandardsISO2813, ISO7668, ASTMD 523, ASTM D2457, GB/T9754, GB/T13891, GB/T7706, GB/T8807
