Cxc-06 Coarse Fiber Analyzer or Raw Fiber Analyzer
Zhejiang Top Cloud-Agri Technology Co., Ltd.- Warranty：One Year
- Element：Organic Elemental Analyzer
- Analysis：Infrared Analysis
- Display：Digital
- Frequency：50±1HZ
- Performance：Automation
Base Info
- Model NO.：CXC-06
- Function：Analyze
- Weight：0-100Kg
- Power Source：AC220V±22V
- Customized：Customized
- Power：AC220V,50Hz, 2800W
- Water Supply：Water Pressure>1.5MPa Water Temperature<20
- Delivery Time：in 15 Days
- Transport Package：Wooden Box, Meet Export Standard Requirements
- Specification：ISO9001
- Trademark：TOP
- Origin：China (Mainland)
- HS Code：9031809090
- Production Capacity：20 Unit,Units Per Week
Description
Feature
1. Raw Fiber Extractor test total fiber and dietary fiber
2. Test acid detergent fiber
3. Test wood and paper fiber and so on
Product description
Raw Fiber Analyzer tests raw fiber content according to acid and alkali boiling methods.
It adopts accurate concentration acid and alkali to boil samples in particular conditions, then remove soluble substances by ether, deducts the number of minerals by high-temperature burning.
Technical parameter
Measuring object: Raw fiber content in various kinds of grain, feed, food, and other agriculture and sideline products
Measuring sample quantity: 6/times
Reproducibility error:
Raw fiber level < 10% absolute value erroe≤ 0.4%
Raw fiber level >10% absolute value error≤ 4%
Measuring time: About 100min (including acid 40min, alkali 40min, filter and wash 20 min)
Power: AC220V/501Hz, 2800W
Water supply: Water pressure >1.5MPa water temperature <20° C
Size: 670× 450× 670mm
Weight: 30kg
