• Model NO.：MSLAB13
• Certificate：ISO, Ce
• Use for：Human
• Rate：35 Tests Samples Per Hour
• Other：81 Reaction Cuvette Positions
• Transport Package：Standard Export Packing
• Specification：CE
• Trademark：MSL
• Origin：China (Mainland)
• HS Code：9027500000
• Production Capacity：1000 Sets,Month

Test principle

Electrical resistence for counting and Cyanide free method for HGB

Clot clear

High voltage burn and high pressure flush

Sample volume

Whole blood: 10uL, prediluted: 20uL

Aperture diameter

WBC:100 um, RBC, PLT: 70um

Chambers

Two chamber

Throughput

60 samples/hour

Language

English,Spanish,French and Chinese

Reference range type

Newborn,children,male,female and general

Display

10.4 inch color touch screen, show all parameters and histograms

Input and output

USB,keyboard,mouse,Parallel Port,RS232 serial port,can be connected to the network by external computer

Working Environment

10°C~35°C; Humidity:≤85% RH

Voltage

AC 110V ~ 240V, 50Hz/60 Hz±1Hz,Auto adapt according to the input voltage

Dimension

370mm×435mm×472mm

Net weight

23Kg

Performance of blood testing equipment (MSLAB13S)

Paramter

WBC(109/L)

RBC(102/L)

HGB(g/L)

MCV(FL)

PLT(109/L)

Linearity

0.3~~99.9

0.20~8.0

10~250

10~99.9

Precision(CV%)

2.5(7.0~15.0)

2(3.5~6.0)

1.5(110~180)

0.5(80.0~110.0)

5(150~500)

Carry over

WBC≤2%

HGB≤2%

RBC≤1%

PLT≤2%
