GDP-8000CM SF6 Gas Dew Point Tester Moisture Detector
HV Hipot Electric Co., Ltd.- Type：Dew Point of Moisture Meter
- Analysis Method：Physical Analysis
- Display：LED
- Application：Electrical
- Portable：Portable
- Physical Analysis Type：Chilled Mirror Method
Base Info
- Model NO.：GDP-8000CM
- Operating Mode：Button
- Heating Mode：Step Heating
- Off Mode：Automatic
- Measurement method：Auto chilled mirror measurement (Stryn refrigerati
- Mirror surface temperature sensor：PRT-100
- Single sample measurement time：90 seconds (stable)
- Operation temperature：-20 ~ +60 centigrade
- Measurement range：-90 ~ +20 centigrade
- Delivery time：1 month
- Dimension：470mm*200mm*400mm
- Transport Package：Standard Export Wooden Box
- Specification：470*200*400mm
- Trademark：HVHIPOT
- Origin：China
- HS Code：9031809090
Description
Measurement methodAuto chilled mirror measurement (Stryn refrigeration principle)Mirror surface temperature sensorPRT-100Single sample measurement time90 seconds (stable)Operation temperature-20ºC ~ +60ºCMeasurement range-90ºC ~ +20ºCAccuracybetter than 0.2ºCResolution0.1ºCRepeatability±0.05ºC dew/frost pointDisplay unitºC, ppm (with a dew point conversion value of 20ºC in the environment)Gas flow400-600mL/minFlow displayImported digital flow meterSample gas pressure≤1MPaEnvironmental humidity90%RHPower supply220VAC ±10%, DC of Li battery (more than 6 hours battery life)Dimension470*200*400mm
