GDWS-242 SF6 Gas Circuit Breaker Transformer Moisture Meter
HV Hipot Electric Co., Ltd.- Type:moisture meter
- Analysis Method:Physical Analysis
- Display:ExtraLCD
- Application:Electrical
- Portable:Portable
- Operating Mode:Touch Screen
Base Info
- Model NO.:GDWS-242
- Heating Mode:Step Heating
- Off Mode:Automatic
- Weight:3.5kg
- Pressure:0-20bar
- Storage:50PCS data.
- Dimension:258*240*88mm
- Transport Package:Standard Export Wooden Box
- Specification:258*240*88mm
- Trademark:HV HIPOT
- Origin:China
- HS Code:9025800000
- Production Capacity:5000 Sets, Year
Description
Basic Info.
Model NO. GDWS-242 Heating Mode Step Heating Off Mode Automatic Weight 3.5kg Pressure 0-20bar Storage 50PCS data. Dimension 258*240*88mm Transport Package Standard Export Wooden Box Specification 258*240*88mm Trademark HV HIPOT Origin China HS Code 9025800000 Production Capacity 5000 Sets/ YearProduct Description
GDWS-242 SF6 Gas Circuit Breaker Transformer Moisture MeterProduct Description
GDWS-242 is ideal instrument when it is necessary to test low dew point and control dry point. It has chemical materials clearing option, which can measure accurately in the environment of high density chemical materials and cleanser. This function can be executed online by control system, also executed regularly by preset time interval.Features
- Zero point calibration, with curve correction.
- With large storage memory and inquiry function.
- Fast measurement speed.
- Easy operation, portable to carry.
- Good repeatability and fast response speed.
- Temperature compensation function.
- AC/DC power supply, built-in rechargeable Li battery, with over-charge and over-discharge protection.
Specification
Measurement range | dew point -80ºC--+40ºC or -60ºC--+60ºC |
Accuracy | ±0.5ºC(with certain range) (when the dew point temperature is below 0 ºC, the sensor output is the frost point) |
Response time | 63% [90%] +20→-20ºC Td 5s[45s] -20→-60ºC Td 10s[240s] |
Resolution | dew point 0.1ºC or 0.1ppm |
Repeatability | ± 0.2 ºC; |
Gas flow | 0.5-0.9L/min(SF6 gas or other gas) 0.1-0.4L/min(H2 gas) |
Pressure measurement | 0-1.0Mpa |
Probe protection | stainless steel sintering filter |
Power supply | 110-220VAC, or Li battery. |
Storage temperature | -40--+70ºC |
Operation temperature | -35--+60ºC |
Pressure | 0-20bar |
Storage | 50pcs data. With management software, including report printing, electronic quality flow meter. |
Dimension | 258*240*88mm |
Weight | about 3.5kg |
Accessories
- Main Tester 1 piece
- Aluminum carry case 1 piece
- Adapter 1 piece
- JQ04 inlet air pipe 1 piece
- CQ02 outlet air pipe 1 piece
- DY03 power cord 1 piece
- TX02 USB wire 1 piece
- User's Guide 1 piece
- Test Report 1 piece
