Digital Color Difference Meter for Smooth Surface
Sino Age Development Technology- Usage:Color Analysis and Color Controlling
- Light Source:C Light Source
- Communication Interface:USB
- Weight (G):204
- Dimension (Mm):171X50X49
- Transport Package:Delivery Package: Carton
Base Info
- Model NO.:SC20
- Specification:CE, SGS, ISO, CIE
- Trademark:SADT
- Origin:China
- HS Code:90318090
- Production Capacity:500 Pieces,Month
Description
Basic Info.
Model NO. SC20 Specification CE, SGS, ISO, CIE Trademark SADT Origin China HS Code 90318090 Production Capacity 500 Pieces/MonthProduct Description
Precise Color Reader SC20 Details:It is made in accordance with the development of the international CIE standard for color difference measurement. Its characteristics are stable performance, high precision, easy to carry and are especially suitable for the production, operation surveying in the scene.
SC20 portable color difference meter is mainly applied to the plastic, metal, printing and painting industries. It makes you capture color efficiently and accurately.
KEY FEATURES:
Easy operation makes you use it easily.
Widely applied to quality control of plastic and printing industries.
Display directly color difference by E*ab, L*a*b, CIE_L*a*b, CIE_L*c*h.
Standard deviation within E*ab0.2 (test condition: Choose average values by 12 pcs white tabula).
I t can be connected with computer to do the inspec tion by sof tware with USB expansion interface.
Model | SC20 |
Accuracy | <0.2 ΔE*ab |
Display | Δ E*ab, CIE_Lab, ΔLab, CIE_Lch |
Light source | C light source |
Test range | L: 0~100, a: -128~127, b: -128~127 |
Test time | About 3 seconds |
Test interval | 2 seconds |
Sensor | Silicon photodiode array |
Working environment | 0~40oC, < 85%RH |
Aperture (mm) | Ø8 |
Power supply | DC/5V (1.5A)/2 x 1.5V (AAA) battery |
Weight (g) | 204 |
Dimension (mm) | 171x50x49 |
