• Model NO.：SC80
• Origin：China
• HS Code：9031809090
• Production Capacity：50 Piece,Pieces , Week

Basic Info.

Model NO. SC80 Origin China HS Code 9031809090 Production Capacity 50 Piece/Pieces / Week

Product Description

PRECISE COLOR READER SC80

Introduction
SC80 precise color reader(color meter, colorimeter) is mainly applied to plastic, painting, design, plating, costume, printing and dyeing industries. SC80 coloimeter can do the color analysis and color controlling. Compared with other color meter, it has many advantages:

Key Features
The 2.4" colorful screen and portable design make you feel comfortable.
3 kinds of light sources for your selection, SCI and SCE mode switch and metamerism analysis satisfy your test needs in different working status.
Tolerance setting, auto-judge color difference values and color deviation make you judge the color easily even you don't have any professional knowledge in color.
Using professional color analysis software you can do the color data analysis and color difference diagrammatic outputting.
Via optional mini printer the color data can be printed out on site.
Similar model: TCR200ModelSC80 ( color meter, colorimeter)AccuracyLighting/Inspecting systemLight sourceInspection angleInspection conditionsRectificationStorageDisplayLanguageAperture (mm)Power supplyNet weight (g)Dimension (mm)


Specifications

0.08 (average value of 30 times @ the standard white tabula)

8/d (8o falloff/diffuse reflection) SCI (include flat mirror light) / SCE (eliminate flat mirror light)

White light source

10 degree angle of view in CIE

D65, D50, F11

White board rectification Black board rectification

12 groups of standard samples, 30 groups of values for each sample

L*a*b*, L*c*h* Chroma values and Δ E*ab Δ (L*a*b*), Δ (L*C*H*) color difference values

English / Chinese

Ø 8

4 pcs of alkaline batteries or nickel batteries special adaptor (DC, 5V)

550g

77x86x210
