• Model NO.：YX-1510
• HS Code：9031809090
• Production Capacity：100 Set,Sets , Month

Basic Info.

Model NO. YX-1510 HS Code 9031809090 Production Capacity 100 Set/Sets / Month

Product Description

Image Measuring Instrument/ surface finish measurement

General Introduction

1, Standard image measuring instrument adopts high density granite for its worktable, the cross worktable is made of advanced cast iron which is exposed in nature environment for a long time and features good stability,

2, The manual moving mode provides economical high efficiency and various humanity measuring function, it can meet different surface measuring requirements, especially for quality inspection in workshop with much more economy, accuracy and utility.

Working Environment:

1. Temperature Range: 20± 5 3/h
2. Humidity Range: 55%-65%
3. Power: 220V± 10%, 50Hz.


Type	YX-1510
Operation Mode	Manual
Travel	150×100
Focus	100
Integrated Error	3.5+L/100(um)
Grating-foot Resolution	1μm
Repeatability Accuracy	≤3μm
Worktable	Toothless smooth lever driving system
Guiding Rail	linear guiding rail
Lens	0.7X4.5X Zoom lens
Camera	Panasonic1/3 color camera
lamp-house	1 set
Software	Measuring software package
Carrying Table Size	240×140
Carrying Weight	20kg
Outer Size (mm)	460×460×680
Weight	90kg

For more detail info, please feel free to visit our website or inquire us at any of your convenience.
