• Model NO.：SC20
• HS Code：9031809090
• Production Capacity：50 Piece,Pieces , Week

Basic Info.

Model NO. SC20 HS Code 9031809090 Production Capacity 50 Piece/Pieces / Week

Product Description

Colorimeter /color reader/ Color Meter SC20
Precise Color Difference Meter SC20

Product Description
SC20 portable color difference meter ( color meter, colorimeter, color reader) is widely applied to quality control of plastic and printing industries. It makes you capture color efficiently and accurately.

KEY FEATURES
1. Easy operation makes you use it easily.
2. Widely applied to quality control of plastic and printing industries.
3. Display direc tly color difference by E*ab, L*a*b, CIE_L*a*b, CIE_L*c*h.
4. Standard deviation within E*ab0.2 (test condition: Choose average values by 12 PCS white tabula).
5. I t can be connec ted with computer to do the inspec tion by sof tware with USB expansion Interface.

Model	SC20
Accuracy	< 0.2 Δ E*ab
Test range	L: 0~100, a: -128~127, b: -128~127
Display	Δ E*ab, CIE_Lab, Δ Lab, CIE_Lch
Sensor	Silicon photodiode array
Aperture (mm)	Ø 8
Light source	C light source
Test time	About 3 seconds
Test interval	2 seconds
Power off	Automatically in 5 min
Working environment	0~40oC, < 85%RH
Power supply	DC/5V (1.5A)/2 x 1.5V (AAA) battery
Net weight (g)	204
Dimension (mm)	171x50x49
Application	Measure any color of smooth surfaces
