• Model NO.：RoughScan
• Origin：China
• HS Code：90318090
• Production Capacity：200 Pieces,Month

Basic Info.

Model NO. RoughScan Origin China HS Code 90318090 Production Capacity 200 Pieces/Month

Product Description

SADT Surface Roughness Tester RoughScan details:



SADT RoughScan tester is a portable, batterypowered instrument for checking surface roughness with the measured values displayed on a digital readout. The instrument can be used in the laboratory, an inspection area, in the shop, or wherever on-site surface roughness testing is required.


Specifications:


Measuring Range: Ra: 0.03μ M~6.3μ M/1μ "~250μ "
Rz: 0.2μ M~50.0μ M/8μ "~999μ "
Ry/Rmax: 0.2μ M~25μ M/8μ "~999μ "

Resolution: 0.01μ M/1μ "
Cut- off: 0.8mm/0.30", ANSI 2RC Filter
Display: 3-digit LCD
Readout Error: ± 10%
Stability: ≤ 6%
Sensor Type: Piezoelectric
Maximum stylus force: 15.0mN/1500mgf
Working Environment: 10oC~45oC
Storage Temperature: 0oC~60oC


Optional Probes:

1. General purpose probe SFP-2001/ SFP-2002
Application: For most sur f a ce roughness applications. SFP-2001 has a 90° Conical diamond st ylus, . 0004"/10μ M radius per ISO standards.
SFP-2002 has a 90° Conical diamond st ylus, . 0002"/5μ M radius per DIN standards.

2. Transverse chisel probe SFP-2003
Application: Fo r gaging sharp edges or small O. D. 's where probe is aligned with (in 180° Or closed position ) to axis of traverse. 9 0 ° Diamond chisel stylus, . 0004"/10μ M radius.

3. Parallel chisel probe SFP-2004
Application: Fo r gaging sharp edges o r small O. D. 's where probe is perpendicular ( in 90 ° Or 270 ° Position ) to axis of traverse. 9 0 ° Diamond chisel stylus, . 0004"/10μ M radius.

4. Small bore probe SFP-2005/SFP-2006
Application: For measuring small bore s (min. Inside diamete r o f 5.0mm, up to a depth of 15.0mm). 90° Conical diamond st ylus, . 0004"/10μ M radius for SFP-2005; 90° Conical diamond st ylus, . 0002"/5μ M radius for SFP-2006.

5. Groove bottom probe
Application: For measuring the bottoms of "O" ring grooves, recesses and holes to depth of 6.0mm. Also used for shor t lands and shoulders. 90° Conical diamond st ylus, . 0004"/10μ M radius.

Traverse length	Evaluation length	Numbers of cutoff
0.5mm	0.25mm	1
1 . 2mm	0.8mm	1
5.5mm	5.0mm	1
1.25mm	0.75mm	3
3 . 0mm	2.4mm	3
5.5mm	5.0mm	3
1.75mm	1.25mm	5
4 . 5mm	4.0mm	5
5.5mm	5.0mm	5
