• Model NO.：TP320.4

Basic Info.

Model NO. TP320.4

Product Description

Introduction

This electronic analytical balance is a popular analytical balance, with sensor of electromagnetic technology and lower structure. The wireless sensor function is added, and the peeling and calibration functions can be controlled with a simple wave of your hand above the sensor window to prevent the sample residue from corroding the button and prolong the service life of the product. This electronic analytical balance has novel, transparent,good visual effects appearance combined with a large operating space. Its stable performance can meet the precise weighing requirements of a wide range of laboratories.



Product features:

★ Modular down-mounted electromagnetic force balance sensor ★ Large LCD screen, clear and bright ★ Transparent glass windshield. The sample is 100% visible ★ All aluminum alloy shell casting, shockproof, dustproof, and radiationproof performance is good ★ Standard RS232 interface module ★ With unit conversion, counting, percentage, printing and other functions ★ Four levels of shockproof, adjustable weighing speed, dynamic temperature compensation ★ Adjustable zero tracking, adjustable automatic tare, simple accumulation ★ With ten-point linear calibration function to ensure that the experimental data is more accurate and reliable ★ Use imported key components to ensure product quality requirements ★ Automatic fault diagnosis, sensor overload protection ★ Built-in type hereafter called hook *Optional animal weighing *Optional density function (special density components are required)




Model	TP320.4
Weighing range (max)	320g
Readability (d)	0.1 mg
Repeatability	±0.2mg
Linear	±0.3mg
Minimum weighing (typical value)	20mg
stable time	3.5s
Preheat time	20-30 min
Weighing unit	g,oz,ct,lb,GN,g/m2,oz/yd2
Weighing pan (stainless steel)	ø 80 mm
Weighing room size (L*W*H)	190×195×240 mm
Dimensions (L*W*H)	350×210×360 mm
Net weight (kg)	7.5
Environment humidity	+5° C to +40° C
Configure calibration weight (F1 level)	200g
Environmental humidity range	20 ~ 80 % RH (Non - Condensing)
Power input voltage	AC 220 V, 50Hz
interface)	RS232C
