• Model NO.：CNY-1218NS
• Trademark：TOP
• Origin：Zhejiang, China (Mainland)
• HS Code：9031809090
• Production Capacity：1000 Set,Sets Per Month

Basic Info.

Model NO. CNY-1218NS Trademark TOP Origin Zhejiang, China (Mainland) HS Code 9031809090 Production Capacity 1000 Set/Sets Per Month

Product Description

Product Description

1. Detection function: multi-functional pesticide and veterinary drug residue detection, integrated edible agricultural product certification printing function.
1.1 It can quickly detect organic phosphorus, carbamates, pyrethroids, herbicides, fungicides, other pesticides, and other pesticides in vegetables, fruits, grains, and tea. Including detection of organophosphates, carbamates, pyrethroids, herbicides, fungicides, and other pesticides.
Contains chlorpyrifos, carbofuran, acetamiprid, omethoate, carbendazim, chlorothalonil, parathion methyl, carbendazim, acetochlor, fenpropathrin, imidacloprid, abamectin, Organophosphorus, aldicarb, alachlor, sporocarp, thiabendazole, fipronil, hydrocarbons, bifenthrin, motion methyl, forchlorfenuron, pyrethroids, paclobutrazol, Chlorothalin, Benthiastrobin, Thiacloprid, Metalaxyl, Parathion, Phoxim, Triazophos, Triadimefon, Paraquat, 4-Chlorophenoxyacetic Acid, 6-Benzyl Adenine, Fenthion, fenthion, chlorpyrifos-methyl, fenthion, iprodione.
1.2 Detection of veterinary drug residues in livestock, poultry, eggs, and aquatic products
1.3. Detection of heavy metals in grains and vegetables
2. Data tracing function: realize the rapid detection of agricultural product safety, the printing of test reports, the safety traceability of agricultural products, and the real-time upload of data to the cloud platform. The two-dimensional code of the certificate can be traced through mobile phone scanning, and the mobile terminal can temporarily implant agricultural products advertisements.
3. Detection module: built-in multi-wavelength spectrum analysis module and immune colloidal gold detection module
4. Pesticide detection range: display and operating system: 10.1-inch color touch capacitive screen, Android operating system.
5. Hardware requirements: 4-core clocked at 1.6GHz, 2G memory, with large-capacity data storage function, built-in SD card expansion function, large-capacity storage of data.
6. Input and output function: intelligent Chinese and English input, handwriting input function, sample name, and intelligent simple spelling input function of the inspected unit. Built-in speaker with video learning function.
7. The scalability of the instrument: open test items, can add and delete test items, expand to 120 items.
8. Detection channels: 12 spectral detection channels and 3 colloidal gold detection channels.
9. Detection and display function: Automatically display the concentration of the test item in the sample and judge whether it is qualified.
10. Data storage function: large-capacity data storage test records, including sample name, sample production unit, test data, test results, and test date.
11. Printing function: Built-in embedded micro thermal printer, directly print the test report of each detection channel and print the self-adhesive certificate.
12. Data processing function: The instrument has data reading, processing, exporting, and transmitting functions, and the test record can be imported into a U disk.
13. Remote management function: The instrument can be remotely managed, remote upgrade, remote control, remote fault diagnosis, and remote training.
14. Communication function: Built-in wireless WiFi and RJ45 network port for direct access to the Internet. Can expand 4G, 5G Internet communication functions, and GPS/AGPS positioning.
15. Data networking function: real-time upload, sharing, and export of detection data. It does not need to be equipped with a computer and can be connected to a third-party monitoring platform.
16. Wavelength: 410nm/412nm
17. Transmittance accuracy: ±2.0%
18. Repeatability of transmittance: ≤0.2%
19. 3-minute stability: ≤0.2%
20. Detection channels: 12
21. Colloidal gold detection modules: 3 (expandable range 5-10)
22. Communication interface: 2 USB
23. Wireless communication interface: Bluetooth, wifi, 3G/4G wireless Internet access
24. Power supply: 220V±10%


Configuration


Serial number	Name	Specification	Quantity
1	Testing equipment	12 channels plus 3 channels colloidal gold	1 set
2	Electronic balance		1 set
3	Mixer		1 set
4	Centrifuge 50ml	4000 rpm	1 set
5	Sample concentrator		1 piece
6	grinder		1 piece
7	Oscillator		1 set
8	Water bath		1 set
9	Pipette	50-250ul	1 piece
10	Pipette	100-1000ul	1 piece
11	Pipette	1000-5000ul	1 piece
12	Glass cuvette	12×12mm	12
13	Extraction cup	40mL	12
14	Beaker	250mL	1 piece
15	Glass test tube	Ø15×100mm	20 pcs
16	Plastic washing bottle	500ml	1 piece
17	Test tube rack	16 holes	1 piece
18	Centrifuge tube rack	50ml	1 piece
19	Centrifuge tube rack	5ml	1 piece
20	Cuvette holder		1 piece
21	Electronic timer	1-99 minutes	1 piece
22	scissors		1 piece
23	Cutter		1 piece
24	Manual		1 serving
25	printer paper	Stickers	2 rolls
26	Ordinary printing paper	Thermal	2 rolls
27	Power Adapter	12V,5A	1 piece
28	Detection reagent
29	Pesticide detection reagent	Organophosphorus carbamate pesticide detection	300 times
30	Acetamiprid Test Card	Immune colloidal gold detection	10 times
31	Chlorpyrifos test card	Immune colloidal gold detection	10 times
32	Carroway test card	Immune colloidal gold detection	10 times
33	Omethoate Test Card	Immune colloidal gold detection	10 times
34	Fluoroquinolone Test Card	Immune colloidal gold detection	10 times
35	Tetracycline Test Card	Immune colloidal gold detection	10 times
36	Chloramphenicol Test Card	Immune colloidal gold detection	10 times
