• Model NO.：T800SCQ-4,T800SCQ-6
• Application：Agriculture & Food
• Operating Mode：Keyboard
• Off Mode：Automatic
• Chemical Analysis Type：electrochemistry
• Heating power：1000W
• Working power：AC 220V, 50Hz;
• Room temperature：99.9 Degree
• Transport Package：Carton Box
• Specification：methylene blue spectrophotometry
• Trademark：Twinno
• Origin：Shanghai, China
• HS Code：9027
• Production Capacity：500 Sets,Month

Basic Info.

Model NO. T800SCQ-4/T800SCQ-6 Application Agriculture & Food Operating Mode Keyboard Off Mode Automatic Chemical Analysis Type electrochemistry Heating power 1000W Working power AC 220V, 50Hz; Room temperature 99.9 Degree Transport Package Carton Box Specification methylene blue spectrophotometry Trademark Twinno Origin Shanghai, China HS Code 9027 Production Capacity 500 Sets/Month

Product Description

T800SCQ-4/T800SCQ-6
Water sulphide acidizing blowing apparatus







Executive standard: determination of sulphide in water quality -- methylene blue spectrophotometry GB T16489-1996, iodine content method HJ/ T60-2000.


Attention:
1. Water quality sulphide -- the acidizing blowing instrument USES AC220V, 50HZ power supply and is well grounded.
2. There are electric heating elements in the instrument. Please keep the instrument away from inflammable and explosive items.
3. Please use it in a ventilated environment.
4. If the cooling fan of the acidizing blowing instrument fails, please do not use it.
5. Before turning on the power, make sure that distilled water, pure water and ionized water have been poured into the water bath pot. Dry burning can damage heating elements.
6. Please stop the sample shelf at any position in the middle when it is stopped, and do not stop the sample shelf at the lowest or highest automatic stop position.


Introduction:
Water quality sulphide - acidification blowing instrument is developed and produced by our company according to the national standard of the People's Republic of China: determination of water quality sulphide - methylene blue spectrophotometry GB T 16489-1996, iodine content method HJ/T60-2000. It fully meets the requirements of sample pretreatment.It is suitable for the determination of sulfide in surface water, groundwater, domestic sewage and industrial wastewater.The acidizing blowing instrument is easy to control, easy to operate and fast.
The instrument is composed of constant temperature water bath, temperature controller, gas distribution, sample rack, lifting system, gas flow control valve, rotameter and so on.

Instrument specifications:
1. Model no. : GL-6224 / GL-6226
2. Number of samples: 4/6
3. Nitrogen flow meter control: 0-10l /min
4. Heating method: constant temperature water bath
5. Heating power: 1000W
6. Temperature range: room temperature -- 99.9ºC
7. Display mode: digital display
8. Temperature control precision: ±1ºC

Instrument features:
1. Different analytical methods such as methylene blue spectrophotometry or iodine quantity method can be selected according to the requirements.
2. According to the requirements of national standard on flow rate, the gas flow rate of 4/6 channel can be precisely controlled to greatly reduce the experimental error.
3. 250mL large capacity iodine flask, which can pretreat 4/6 samples at the same time.
4. Each reaction bottle is an independent gas path system to avoid cross-contamination of samples and save gas.
5. Closed air path system, exhaust gas can be discharged out of the room or absorbed for treatment, to avoid the harm of harmful gas to the experimenter.
6. Adopt constant temperature water bath heating, cooperate with temperature control system, have good temperature uniformity.
7. Take use of high quality mirror stainless steel material, with excellent performance.
8. Manual lifting system is applied to the main machine, and the sample tray can be rotated to facilitate experimental operation.
9. Multi-color gas pipeline can quickly clean the gas pipeline system.

 Product configuration:

No.	Name	Quantity
1	Host	1
2	Absorption color rendering tube 70ml	8/12
3	Sample holder	1
4	Connection pipe	1
5	Spring	1
6	Power cord	1
7	Plus the acid funnel	4/6
8	Reaction bulb	4/6
9	Certificates	1
10	Warranty card	1
11	Operation instruction	1
