- Model NO.：68
- Transport Package：Carton Case
- Specification：SGS
- Trademark：SAMYON
- Origin：Cn
- HS Code：903180
- Production Capacity：100sets Per Month
| Product Name | Gloss meter | | |
| Model | 68 | | |
| Measurement Range | 20°:0-2000; 60°:0-1000Gu; 85°:0-160Gu | | |
| Application | Apply on paint, ink, stoving varnish, coating, wood products; Marble, granite, vitrified polished tile, pottery brick and porcelain; Plastic, paper; Other nonmetallic material. | | |
| | |
| | |
| | |
| Instrument Dimensions | 159x49x72mm | | |
| Projection Angle | 20° 60° 85° | | |
| Measuring Spot | (ellipse: long axis*minor axis)20°: 10x10 / 60°:9x15/ 85°:5x18 | |
| Measuring Mode | Statistics Mode/sampling Mod/Continuous Mode/manual measurement/single measurement/average measurement and cross measurement for a variety of combination measuring mode | | |
| Standard Sample Setting | Manually setting/bring out stored data for setting/manually setting tolerance | | |
| Data Storage | 5000 groups | | |
| Language | Chinese/English | | |
| Output | connect the micro printer to realize real-time output of measured data | | |
| Division Value | 0-1000:0.1 1000-2000:1 | | |
| Repeatability | 0-100:0.2 >100:0.2% | | |
| Indication Error | ±1.5 | | |
| International Standard | ISO-2813,ASTM-C584,ASTM-D523,DIN-67530,ASTM-D2457,JND-A60,JND-P60 | | |
| Standard Accessories | Power adapter/user manual/warranty certification/standard board/software GlossW | | |
| Optional Accessories | micro-printer PC color analysis | | |
