Atex Approved DC24V Fixed No No2 So2 Cl2 Gas Detector Monitor (BS03)

HANWEI ELECTRONICS GROUP CORPORATION
  • Brand:Hanwei Electronics
  • Customized:Customized
  • Portable:Non Portable
  • Certification:RoHS, Atex
  • Gas:Combustible, Toxic Gas
  • Type:Fixed Gas Detector

Base Info

  • Model NO.:BS03
  • Working Method:Natural Diffusion
  • Working Voltage:DC24V±25%
  • Signal Output:4-20mA Signal or RS485 Signal
  • Ingress Protection:IP65
  • Transmission Distance:≤1000m
  • Power Consumption:2W
  • Mounting Type:Wall Mounted
  • Dimension and Weight:162 X 208 X 103.5mm, About 2.1kg
  • Transport Package:Carton
  • Origin:China Mainland
  • Production Capacity:2000PCS

Description

Basic Info.

Model NO. BS03 Working Method Natural Diffusion Working Voltage DC24V±25% Signal Output 4-20mA Signal or RS485 Signal Ingress Protection IP65 Transmission Distance ≤1000m Power Consumption 2W Mounting Type Wall Mounted Dimension and Weight 162 X 208 X 103.5mm, About 2.1kg Transport Package Carton Origin China Mainland Production Capacity 2000PCS

Product Description

Description
BS03 is a fixed gas detector installed in a place where potential gas hazard exists to measure oxygen, toxic gas and combustible gas. It shows not only the concentration of gas but also diagnostic result of the unit itself through the LED screen and LED lights and can be connected to the control panel with a standard 4-20mA analog output.

Features
BS03 measures the concentration of the flammable gas, toxic gas, oxygen and VOCs
Explosion proof structure.
Water and dust proof design
Segment display to indicate readings in 4 digits.
3 LED lights to indicate Fault, Low alarm and High alarm
IR remote control for setting and calibration.


Application
Steelworks, Petrochemical plants, Shipyards, Water treatment plants, Mines, Power plants, Food industry etc.

Product Pictures

Atex Approved DC24V Fixed No No2 So2 Cl2 Gas Detector Monitor (BS03)


Atex Approved DC24V Fixed No No2 So2 Cl2 Gas Detector Monitor (BS03)
Atex Approved DC24V Fixed No No2 So2 Cl2 Gas Detector Monitor (BS03)

Atex Approved DC24V Fixed No No2 So2 Cl2 Gas Detector Monitor (BS03)
Atex Approved DC24V Fixed No No2 So2 Cl2 Gas Detector Monitor (BS03)
Atex Approved DC24V Fixed No No2 So2 Cl2 Gas Detector Monitor (BS03)

Atex Approved DC24V Fixed No No2 So2 Cl2 Gas Detector Monitor (BS03)
