HK-8100 Icp Plasma Emission Spectrometer
Beijing Samyon Instruments Co., Ltd.- Features：High Precision,High Sensitivity and High Stability
- Transport Package：Carton
- Trademark：SAMYON
- Origin：Cn
Base Info
- Model NO.：HK-8100
- HS Code：903180
- Production Capacity：1000 Sets Per Month
Description
ICP Series production is high precision, high sensitivity and high stability inductively coupled plasma emission spectrometer. It is based on the traditional inductively coupled plasma emission spectrometer technology, absorbing the latest international technological achievements. Our company is on the basis of many years' scientific research, technology sharing, and continuing development of innovation. Our rich experience, solid improvement, and the enthusiastic expertise ensure the quality of service we supply. ICP, as a large-scale inorganic analytical instruments, is widely used in analysis of rare earth and precious metals analysis, alloy materials, electronics, medicine, metallurgy, geology, petroleum, chemical, commodity inspection, environmental protection and other departments and NdFeB, silicon, ferrosilicon , Tungsten, molybdenum, etc., from trace to the common of the qualitative or quantitative analysis. It integrates light, mechanical, electrical, computer, analysis techniques in one high-tech products, have the advantages of high test speed, wide range, accurate and reliable analysis of the characteristics. In sum, because of the computer technology, intelligent devices, the screen shows graphics, text and data collection, processing and so on, HK-8100 Series is the best choice as the analysis device.
Equipment components and working principle
ICP inductively coupled plasma single-channel scanning spectrometer, is a multi-element analysis of the sequence test measuring equipment. The instrument consists of scanning spectrometer, radio frequency generator, the sample introduction system, photoelectric conversion, control systems, data processing systems, and analysis software. Plasma is generated from the triple concentric quartz tube in a torch. Argon is put into Torch pipe in tangent direction, the upper part of torch is coiled with copper loop <intercom cooling water>. High-frequency generator generates the high frequency current (40 MHz frequency around 1 KW power) through the coil, producing around Alternating magnetic field, ionizing to produce a small amount of argon ion and electron, in the magnetic field under the accelerated collisions with other neutral atoms, producing more electronic and ions, in the form of eddy current, EDM reacts in the plasma formed under the plasma torch (That is, plasma). The plasma temperature could be up to 10000 K or higher. Aqueous solution measured by the formation of aerosol spray into the center of the quartz torch channel. Atomic is ionized by energy of outsiders, but the atoms are in unstable state, and from the high-level transition to the ground state, atoms will release tremendous energy, this energy is a certain wavelength of electromagnetic radiation and is sent out. Different elements have different spectral characteristics. These feature spectrum shoots grating of spectrometer through the lens, computer rotates grating by controlling the stepper motor, transmission mechanism posit elements characteristic spectra accurately to the slit, and photomultiplier change the spectrum of light intensity to the current, then deal with the circuit and V / F conversion by computer data processing, the final analysis is made by the printer.
