• Model NO.：HPC601
• Gas：Gas
• Type：Smoke Opacimeter
• Name：Exhaust Gas Analyzer
• Measurement Range：Dew Point: -80~+20ºC
• Precision of Dew Point：±0.5ºC
• Resolution Ratio：Dew Point 0.1ºC or 0.1ppm
• Repeatability：±0.5ºC
• Precision and Repeatability：±0.5%, Have Nothing to Do with The Flow
• Gas Measurement Range：H2s:1 ~ 200ppm
• Work Voltage：220VAC±10% 50Hz
• Pressure：0~20bar
• Output Interface：USB1.1 Specification
• Transport Package：Wooden Box with Foam Inside
• Specification：CE,ISO,IEC
• Trademark：HuaZheng
• Origin：China
• HS Code：9031809090
• Production Capacity：100 PCS,Month

Basic Info.

Model NO. HPC601 Gas Gas Type Smoke Opacimeter Name Exhaust Gas Analyzer Measurement Range Dew Point: -80~+20ºC Precision of Dew Point ±0.5ºC Resolution Ratio Dew Point 0.1ºC or 0.1ppm Repeatability ±0.5ºC Precision and Repeatability ±0.5%, Have Nothing to Do with The Flow Gas Measurement Range H2s:1 ~ 200ppm Work Voltage 220VAC±10% 50Hz Pressure 0~20bar Output Interface USB1.1 Specification Transport Package Wooden Box with Foam Inside Specification CE/ISO/IEC Trademark HuaZheng Origin China HS Code 9031809090 Production Capacity 100 PCS/Month

Product Description

China Manufacturer Diesel Gas Analyzer Opacity Smoke Meter Opacimeter Price

I.Main Features

Integrated Structural Design
Adopted a triage-type sampling technique, diesel engine acceleration, deceleration, and steady speed can be measured when the smoke
Linear automatic data processing, can be displayed opacity degrees N, light absorption coefficient K and the corresponding value of filter paper-type smoke SF
High-brightness digital display;
Use of "air curtain" technology to protect the optical system from pollution
Automatic detection of room temperature control, anti-condensation can affect the testing accuracy
Automatically attached to the time display, and optional speed measurement and oil temperature measurement
Show where the failure of automatic diagnosis unit;
Equipped with built-in printer (or digital RS-232A interface or analog interface)

In line with ISO11614 and GB3847-2005 technical requirements.



II.Technical Parameters

Test Scope:No light transmission      N:0~100% (equivalent to smoke value 0~10FSN)

           Light absorption coefficient K:0~16.06 m^-1

           RPM:0~9990rpm    OIL TEMP: 0~150ºC

Indication error: ≤±2% ( measured value)

Stability:moment drift≤±1%/4H

Repeatability ≤±1%

Resolution: N:0.1%, K:0.01m^-1 ,RPM:10rpm, OIL TEMP:0.1ºC

Output mode:digital direct reading, can be attached to the printer to print the smoke concentration ( darkness) maximum value, test time, date. Can interface with computer networking

The measurement chamber temperature:

   70 ºC (automatic), when the temperature error of ≥± 10%, temperature and error indicator light

And-use temperature: -5~50°C,  Relative humidity: ≤90%

Power: AC100~240V 50/60Hz or DC12V,  Power consumption: 150VA

Dimensions ( including bracket) :160 ( L)×400(W)×480 (H)mm

Weight:  8kg

III.Company Information

HuaZheng Electric Manufacturing (Baoding) Co.,Ltd is the supplier of the State Grid in China.It means we are the supplier of the Chinese Government.And our products spread throughout the whole China.

What's more, our customers come from different countries like America, England, Bulgaria, Brazil, Chile, Malysia, Vietnam and so on.

Our main products are Insulation Oil Tester, Cable Fault Locator, Power Quality Analyzer, High Voltage Generator, High Voltage Capacitor, Testing Transformer and so on.
