Sf6 Purity Tester Sf6 Concentration (%) Purity Meter Sf6 Analyser
EP HIPOT ELECTRIC CO., LTD.- After-sales Service：Onsite and Remote Guidance
- Warranty：1 or 2 Years Free Warranty Longlife Service
- Brand：Ephipot
- Customized：Customized
- Portable：Portable
- Certification：CE
Base Info
- Model NO.：EPDP
- Gas：Sf6
- Type：Electrochemical Gas Analyzer
- Measuring Range：0~100 Percentage
- Measuring Precision：+-0.5c(-60c~+20c)
- Measuring Duration(+20c)：<3 Minutes
- Environmental Temperature：-40c~+60c
- Environmental Humidity：0~100% Rh
- Power：AC 220V
- Build-in：Rechargeable Lithium Battery
- Battery Capacity：20 Hours Charging, 10 Hours Continuous Working.
- Gas Consumption：2L(101.2kpa)
- Keywords：Sf6 Gas Analyser
- RS232 Port：to Connect with Printer.
- Meter：Electronic Flow
- Valve：Regulating
- Sf6 Volume：Percentage
- LCD Screen：Purity Value, Time,Date, Battery Capacity
- Transport Package：Plywood Case with Foam and Warterproof Plastic
- Specification：258mm X 240mm X 120mm
- Trademark：EP Hipot
- Origin：Wuhan, China
- HS Code：903180909
- Production Capacity：2000,Year
Description
Power sourceAC: 220V±10%,50Hz DC: Build-in rechargeable lithium battery Air consumption 200~600mL/min Storage capacity 60 pieces Operation mode Touch screen Communication interface RS232 or USB to communicate with the host computer Printing Build-in printer with thermal English report type printing Weight 5.5kg Oversize 300mm X 400mm X 150mm
More details on SF6 Gas Analyser please contact EP Hipot Electric, we have professional tech team to design correctly designed products and systems.
