SF6 Gas Decomposition Product H2S & HF Detector with Good Repeat-ability
HV Hipot Electric Co., Ltd.- Brand：HV HIPOT
- Portable：Portable
- Certification：CQC
- Gas：SF6 Gas decomposition products analyzer
- Sampling：Built-in flow valve, flowmeter
- Working temperature：-20ºC~55ºC
Base Info
- Model NO.：GDFJ-II
- Working humidity：≤90%RH
- Power：DC built-in rechargeable battery; AC 220V,50Hz
- Storage：100 sets test data
- Printer：built-in printer
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan China
- HS Code：9027100090
- Production Capacity：5000sets,Year
Description
Basic Info.
Model NO. GDFJ-II Working humidity ≤90%RH Power DC built-in rechargeable battery; AC 220V/50Hz Storage 100 sets test data Printer built-in printer Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9027100090 Production Capacity 5000sets/YearProduct Description
GDFJ-II SF6 Gas Decomposition Products AnalyzerI. General Information
GDFJ-II SF6 gas decomposition products analyzer is the device easy to test SF6 gas decomposition products.In the process of test,connect the device with equipment full of SF6 gas.When SF6 gas flow sensors with certain speed,the instrument can measure the content of SF6 gas main decomposition products. Sensors are special for SF6 gas,long lifespan design,accurate testing results. Main application include fault location,partial discharge monitoring,gas purification/filter monitoring,fault high voltage contact detection,SF6 decomposition products detection,switch decomposition products detection.
II. Features
* Long lifespan detecting components.
* High precision,good repeatability.
* Built-in voltage stabilization device and Electronic mass flowmeter.
* Large LCD display
* Light and portable
* AC/DC both ok,built-in rechargeable battery
* Fast response,no preheat waiting.
* Test results is not influenced by environmental temperature.
III. Technical specifications
| Measuring range | H2S:0~200µL/L SO2: 0~200µL/L HF:0~10µL/L optional CO: 0~1000µL/L optional |
| Sensitivity | 0.1 µL/L |
| Sampling flow rate | 0.25 L/min±30ml/min |
| Response time | 10~15s |
| Intake pressure | ≤1.0MPa |
| Sampling | Built-in flow valve, flowmeter |
| Working temperature | -20ºC~55ºC |
| Working humidity | ≤90%RH |
| Power | DC built-in rechargeable battery; AC 220V/50Hz |
| Storage | 100 sets test data |
| Printer | built-in printer |
| Output interface | USB interface |
| Dimension | 335*290*160mm |
| Weight | 5.7kg |
